Factory Mould 2 Color Round Recessed Led Panel Light RGB Ceiling Light 6+3W
Factory Mould 2 Color Round Recessed Led Panel Light RGB Ceiling Light 6+3W
Factory Mould 2 Color Round Recessed Led Panel Light RGB Ceiling Light 6+3W
Factory Mould 2 Color Round Recessed Led Panel Light RGB Ceiling Light 6+3W
Factory Mould 2 Color Round Recessed Led Panel Light RGB Ceiling Light 6+3W
Factory Mould 2 Color Round Recessed Led Panel Light RGB Ceiling Light 6+3W
Factory Mould 2 Color Round Recessed Led Panel Light RGB Ceiling Light 6+3W
Factory Mould 2 Color Round Recessed Led Panel Light RGB Ceiling Light 6+3W
Specifications
Brand Name :
XENTER
Model Number :
XT-SMSQ-6+3W
Certification :
BIS CE RoHS IP65
Place of Origin :
China
MOQ :
500pcs
Supply Ability :
5000pcs/day
Delivery Time :
25-30 days
Packaging Details :
color box, standard export carton
Rated Watt :
6+3W
Color Temperature :
White+PGB
Driver :
Isolated
Voltage :
AC85-265V
Lamp Body Material :
Die Cast Aluminium
Light Source :
SMD 2835
CRI :
>70
PF :
>0.5
Description

Factory Mould 2 Color Round Recessed Led Panel Light RGB Ceiling Light 6+3W


Product Advantages

• Factory moulds 2 color panels series

• Heavy housings, thicker arcylic rings, top grade apperance

• Patent design output cable,

• Power : 3+3W, 6+3W, 12+4W, 18+6W

• Color combination: white+blue, white+green, white+pink, white+red, white+WW, white+PGB

• With BIS approvals

Square Two Color LED Panel Light 6+3W

Color Temperature WH+BL, WH+GR, WH+WW, WH+RD, WH+PK, WH+PGB
Wattage 6+3W
Mount Type Concealed
Shape Round
Dimmension (mm) Ø145*30
Cut Out Size (mm) Ø110
Work Voltage AC85-265V
Lamp Type SMD2835
Housing Materials Die cast Aluminium
Frequency 50/60Hz
LED Driver Isolated
Power Factor >0.5
Colour Rendering Index (CRI) Ra>70
Warranty 2 years



Dual Color LED Panel Light Specification

Shape Watt Driver Voltage Size
(mm)		 Cutout
(mm)		 PCS/CTN CTN Size
(cm)

Round

 3+3W

Isolated

AC85-265V

 ø105*30 ø75 50 69.5*22*26
6+3W ø145*30 ø110 40 42*35*33
12+4W ø190*30 ø160 20 42*23*42
18+6W ø240*30 ø210 20 45*44.5*24

Square

 3+3W

Isolated

AC85-265V

 105*105*30 75*75 50 69.5*22*26
6+3W 145*145*30 110*110 40 42*35*33
12+4W 190*190*30 160*160 20 42*23*42
18+6W 240*240*30 210*210 20 45*44.5*24

Factory Mould 2 Color Round Recessed Led Panel Light RGB Ceiling Light 6+3W

Lighting Applications

1. General room lighting in ceilings, suspended ceilings

2. Interior lighting such as bed room, class room, study room, super market, store, wareshouse

3. Coffered ceiling lighting

4. Cabinet lighting

5. Lobby lighting

6. KTV, hotel ,restaurant, bars, museum, movie theater etc


Warnings

1. Cut off the power before installation
2. Can't be used as emergency light
3. To keep them away for the flammable objects.
4. The environment temperature of the lamp operation: -20Ċ to +60Ċ
5. Do not try to open this unit , to have the professional person to open it
6. Internal lighing only, can be used outside lighting
