5000psi Quick Union Wireline Lubricator For Wellhead
5000psi Quick Union Wireline Lubricator For Wellhead
5000psi Quick Union Wireline Lubricator For Wellhead
5000psi Quick Union Wireline Lubricator For Wellhead
Specifications
Brand Name :
Techcore
Model Number :
FPG 7-35
Certification :
ISO, BV
Place of Origin :
CHINA
MOQ :
1 set
Price :
Negotiable
Supply Ability :
200 sets/month
Delivery Time :
30-45 days
Packaging Details :
Polly wood, suitable for sea and air shipment
Application :
Wellhead pressure control
Product :
Light weight lubricator
Working pressure :
5000psi
Service :
Standard Oil well condition
Standard :
NACE MR0175 & API 6A
Usage :
Wireline pressure control
Connection :
Quickly union
Material :
Alloy steel
Description

Quick Union Wireline Lubricator For Wellhead Pressure Control​

The integral lubricator is the component of wellhead pressure control equipment used in oil & gas well wireline operation. The Wireline Lubricator is a tube completed which with quick union and can stand high pressure. The lubricator is used to accommodate wireline tool string, and enable the wireline tool string to be run or retrieved from a well bore under pressure. The lubricator can be used in singal or in multy

according to the requirement of the oilfield operation,but the seal control head always be assembled on the top of the lubricator. The single length of lubricator is 0.8m - 3m.

Specification of Integral Lubricator

Model ID/mm Connection Working pressure Cable Size/mm Working condition Working pressure
FPG6-35 62 4 1/4”-6SA 5000 psi Dia 1.8 - Dia3.2 Crude oil, water, natural gas with H2S and CO2 -29oC to +121oC
FPG7-35 76 5”-4ACME
FPG10-35 103 7 3/4”-5ACME
FPG6-70 62 4 3/4”-4ACME 10000psi
FPG7-70 76 5 3/4”4ACME
FPG10-70 103 8 3/8”-4ACME
FPG7-105 76 7 3/4”-4ACME 15000psi
FPG10-105 103 9 1/2”-4ACME
FPG6-70T 62 4 3/4”-4ACME 10000psi
FPG7-70T 73 5 3/4”-4ACME
FPG10-70T 103 8 3/8”-4ACME

5000psi Quick Union Wireline Lubricator For Wellhead 5000psi Quick Union Wireline Lubricator For Wellhead

About Techore Oil Tools

With the professional Research and Development (R&D) department and skilled engineers whom were committed to the design of downhole tools for more than ten years, Techcore Oil Tools equipped with advance equipment is specialized in manufacture the oil downhole tools and its related parts in high quality.

* Techcore insist on superior quality, strong packing & timely delivery.

* Third party inspection is available from SGS, BV, DNV etc.

* Techcore do the best to supply thoughtful and prompt after-sales service to guarantee for the customers' benefits

* Techcore supply the cost effect products with 12 months guarantee

* Techcore insist on the traceability of each Drill stem testing tools and related DST parts from the raw material to the finished products to meet on requirements of onshore and offshore standards

Wellhead Pressure Control Equipment For Wireline Operation

Wireline RAM BOP, Wireline Grease Injection Control Head, Quick Test Sub, Pump-in Sub, Slickline Stuffing Box / Hydraulic Seal Head, Top and Bottom Sheaves, Integral Lubricator, Hydraulic Tool Catcher, Wireline Cable Cutter, Tool Trap, Bleed-off Sub, Crossover Sub / Wellhead Adapter
