700Bar Stainless Steel Pressure Transmitter IP65 YW-130 Aviation Plug-In Pressure Transmitter
700Bar Stainless Steel Pressure Transmitter IP65 YW-130 Aviation Plug-In Pressure Transmitter
700Bar Stainless Steel Pressure Transmitter IP65 YW-130 Aviation Plug-In Pressure Transmitter
700Bar Stainless Steel Pressure Transmitter IP65 YW-130 Aviation Plug-In Pressure Transmitter
700Bar Stainless Steel Pressure Transmitter IP65 YW-130 Aviation Plug-In Pressure Transmitter
700Bar Stainless Steel Pressure Transmitter IP65 YW-130 Aviation Plug-In Pressure Transmitter
700Bar Stainless Steel Pressure Transmitter IP65 YW-130 Aviation Plug-In Pressure Transmitter
700Bar Stainless Steel Pressure Transmitter IP65 YW-130 Aviation Plug-In Pressure Transmitter
700Bar Stainless Steel Pressure Transmitter IP65 YW-130 Aviation Plug-In Pressure Transmitter
700Bar Stainless Steel Pressure Transmitter IP65 YW-130 Aviation Plug-In Pressure Transmitter
Specifications
Brand Name :
XINYI
Model Number :
YW-130
Certification :
CE
Place of Origin :
China
MOQ :
1
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
1000 pcs/Month
Delivery Time :
5 work days
Packaging Details :
carton
Name :
Stainless Steel Pressure Transmitter
Range :
-100~700kPa~70MPa
Pressure type :
Gauge pressure/Absolute pressure/Seal pressure
Output signal :
4-20mA、0~5V、0.5~4.5V
Power supply :
9-24 VDC
Accuracy class :
0.5%FS/0.2%FS
Compensation temperature :
-10~70℃
working temperature :
-20~80℃
Protection level :
IP65
Description

700Bar Stainless Steel YW-130 Aviation Plug-In Pressure Transmitter

The aviation plug-in pressure transmitter uses a pressure sensor with a stainless steel isolation membrane as the signal measurement element, and has been automatically tested by a computer. The zero point and temperature performance compensation of a wide temperature range has been carried out using laser resistance adjustment technology. The signal processing circuit is located inside a stainless steel casing and converts sensor signals into standard output signals. The entire product has undergone rigorous testing and aging screening of components, semi-finished products, and finished products, with stable and reliable performance. This product is widely used for pressure measurement and control in industrial process sites such as petroleum, chemical, metallurgical, power, and hydrological industries due to its reliability, flexibility, and diversity.

All stainless steel structure;
Multiple structures to choose from;
Compact in size and easy to install;
Standard thread pressure measurement method;
Gauge pressure, absolute pressure, and sealed gauge pressure;
Laser resistance compensation zero point and temperature performance;
High reliability and stability;
The output signal forms are diverse;
Constant current source power supply;
Reverse polarity protection and instantaneous overcurrent and overvoltage protection comply with EMI protection requirements;

Product Name Aviation plug-in pressure transmitter
Zero temperature drift 0.5%FS
Sensitivity temperature drift 0.5%FS
Pressure overload 2 times below 10MPa; 1.5 times above 25MPa
Mechanical vibration 20g
Sampling time 2400/S
Long term stability ≤0.2%FS/year
Isolation 100MΩ/250VDC
