Specifications
Price :
CN¥1,154.13/sets 1-19 sets
warranty :
2 years
customized support :
OEM, ODM, OBM
place of origin :
Shaanxi, China
brand name :
XINYIYB
model number :
PGS23.100
type :
Bourdon Tube Pressure Gauges
material :
SS316
size :
30*20*20cm
weight :
3kg
Product Name :
Diaphragm Pressure Gauge
Range :
0 ... 0.6 bar to 0 ... 1,600 bar
Material :
Stainless Steel Case
Ambient :
-20 ... +60 °C
Accuracy :
1.0%FS
Case filling :
Optional
Medium :
+200 °C
Scale :
Single scale, Option: Dual scale
Connection :
Thread Optional
Ingress protection :
IP65
Description

PGT23.100 Stainless Steel Manometer Diaphragm Seal Pressure Gauge With 1.0%FS Accuracy And IP65 Ingress Protection

Products Description

Diaphragm Pressure Gauge

Bourdon tube pressure gauge with switch contacts For the process industry, NS 100 and 160 Models PGS23.100 and PGS23.160The pressure gauge is manufactured in accordance with DIN 16085 and fulfils all requirements of the relevant standards (EN 837-1) and regulations for the on-site display of the working pressure of pressure vessels. As switch contacts, magnetic snap-action contacts, reed switches, inductive contacts and electronic contacts are available. Inductive contacts can be used in hazardous areas. For triggering programmable logic controllers (PLC), electronic contacts and reed switches can be used.
Special features
Up to 4 switch contacts per instrument
■ Also available with case filling for high dynamic pressure loads or vibrations
■ Instruments with inductive contacts for use in hazardous areas
■ Instruments with contacts for PLC applications
■ Instruments optionally available in safety version S3 per EN 837
Applications
Control and regulation of processes
■ Monitoring of plants and switching of circuits
■ For gaseous and liquid aggressive media that are not highly viscous or crystallising, also in aggressive environments
■ Chemical industry, petrochemical industry, power plants, mining, on-/offshore, environmental technology, machine building andgeneral plant construction
PGT23.100 Stainless Steel Manometer Diaphragm Seal Pressure Gauge With 1.0%FS Accuracy
PGT23.100 Stainless Steel Manometer Diaphragm Seal Pressure Gauge With 1.0%FS Accuracy
PGT23.100 Stainless Steel Manometer Diaphragm Seal Pressure Gauge With 1.0%FS Accuracy
PGT23.100 Stainless Steel Manometer Diaphragm Seal Pressure Gauge With 1.0%FS Accuracy
PGT23.100 Stainless Steel Manometer Diaphragm Seal Pressure Gauge With 1.0%FS Accuracy
Specification
Product Name
Diaphragm Pressure Gauge
Models
PGS23.100
Accuracy class
1.0%FS
Scale ranges
0 ... 0.6 bar [0 ... 8.7 psi] to 0 ... 1,600 bar [0 ... 23,206 psi]
other units (e.g. psi, kPa) available
Scale
Single scale Option: Dual scale
Process connection
■ G ½ B
■ G ¼ B
■ G ⅜ B
■ ½ NPT
■ M20 x 1.5
others on request
Medium temperature
+200 °C [+392 °F] max.
Ambient temperature
-20 ... +60 °C [-4 ... 140 °F]
Ingress protection
IP65 Option: IP66
