5500 CD Brightness P12 Outdoor Advertising LED Display With 2R1G1B
5500 CD Brightness P12 Outdoor Advertising LED Display With 2R1G1B
5500 CD Brightness P12 Outdoor Advertising LED Display With 2R1G1B
5500 CD Brightness P12 Outdoor Advertising LED Display With 2R1G1B
5500 CD Brightness P12 Outdoor Advertising LED Display With 2R1G1B
5500 CD Brightness P12 Outdoor Advertising LED Display With 2R1G1B
Specifications
Place of Origin :
China
Brand Name :
Dreamway
Certification :
CE,ROHS
Model Number :
P12
MOQ :
negotiable
Price :
negotiable
Packaging Details :
Plywood case
Delivery Time :
20 days after receiving the deposit
Payment Terms :
T/T
Supply Ability :
2000sq.m/Month
Description



5500 CD Brightness P12 Outdoor Advertising LED Display with 2R1G1B


Quick Detail:

1. 2R1G1B;
2. 6,944 dots/sq.m;
3. 192×192 mm LED module;
4. QZ / Silan LED chip;
5. R9 GB8×10;
6. JXI5020 driving IC.


Detail Description:

HUB board and PCB are separated, not easy to get heated;
Not less than 5500 nits per square meter, good to show video;
Steel water resistance LED box, no problem to work even with bad weather;
We provide 2 years warranty for this type.


Specifications:

Pixel Pitch

12mm

LED Composition

2R1G1B

LED Type

DIP346

Resolution

6,944 dots/sq.m

LED Module Pixel

W 16 × H 16

LED Module Size

W 192 × H 192 mm

Normal Cabinet Size

W 960 × H 960 mm

Cabinet Color

Black

Cabinet Material

Steel waterproof

Drive Method

1/4 scan constant current

Brightness

≥5500 nits/sq.m

Refresh Rate

≥800Hz

Out of Control Dot Rate

＜0.0001

Earth Leakage Current

＜2mA

MTBF

＞5,000 hours

LED Life Span

＞100,000 hours

Power Supply

110V/60HZ and 220V/50HZ interchangeable

Humidity

10%~90%

Control System

NovaStudio

Operation System

Win2000 / XP / Vista


P12 Outdoor Advertising LED Display, Outdoor LED Display Board Advertising, Advertising LED Display Outdoor
