Asynchronous Double Sides P20 LED Pharmacy Cross Signs DIP 546 with 960 × 960 mm Screen
Asynchronous Double Sides P20 LED Pharmacy Cross Signs DIP 546 with 960 × 960 mm Screen
Asynchronous Double Sides P20 LED Pharmacy Cross Signs DIP 546 with 960 × 960 mm Screen
Asynchronous Double Sides P20 LED Pharmacy Cross Signs DIP 546 with 960 × 960 mm Screen
Asynchronous Double Sides P20 LED Pharmacy Cross Signs DIP 546 with 960 × 960 mm Screen
Asynchronous Double Sides P20 LED Pharmacy Cross Signs DIP 546 with 960 × 960 mm Screen
Asynchronous Double Sides P20 LED Pharmacy Cross Signs DIP 546 with 960 × 960 mm Screen
Asynchronous Double Sides P20 LED Pharmacy Cross Signs DIP 546 with 960 × 960 mm Screen
Asynchronous Double Sides P20 LED Pharmacy Cross Signs DIP 546 with 960 × 960 mm Screen
Asynchronous Double Sides P20 LED Pharmacy Cross Signs DIP 546 with 960 × 960 mm Screen
Specifications
Place of Origin :
China
Brand Name :
Dreamway
Certification :
CE,ROHS
Model Number :
P20
MOQ :
negotiable
Price :
negotiable
Packaging Details :
Plywood case
Delivery Time :
20 days after receiving the deposit
Payment Terms :
T/T
Supply Ability :
200PCS/Month
Description

Double Sides P20 LED Pharmacy Cross Display with 960×960 mm Screen Size

Quick Detail:

1. 960 by 960 mm for screen size;

2. 1000 by 1040 mm of cabinet dimension;

3. Plywood box packing;

4. Showing temperature, date, animation, graphics, etc;

5. Lifting circle and mounting plate on the cabinet;

6. Controlled by WIFI.

Detail Description:

Could display different countries languages, such as French, Russian, Italian, Greek, etc;

Lifting system provided for more convenient installation;

Friendly operation software, easy control.

Specifications:

Pixel Pitch

20mm

LED Composition

1G

LED Type

DIP546

Pixel

2500 dots/sq.m

Module Pixel

W 16 × H 8

Module Size

W 320 × H 160 mm

Cabinet Size

W 1000 × H 1040 mm

Cabinet Material

Steel water resistance

Drive Mode

1/4 scan constant current

Luminance

≥2000 nits/sq.m

Refresh Rate

≥200Hz

Out of Control Dot Rate

＜0.0001

Earth Leakage Current

＜2mA

MTBF

＞5,000 hours

Life Span

＞100,000 hours

Power Supply

110V/60HZ and 220V/50HZ interchangeable

Humidity

10%~90%

Control Method

Asynchronous control

Operation System

Win2000 / XP / Vista


Wireless Control LED Pharmacy Cross Display, Green LED Pharmacy Cross Display, LED Pharmacy Cross Display Wholesale Price
