Specifications
Brand Name :
Dreamway
Model Number :
P6
Certification :
CE,ROHS
Place of Origin :
China
MOQ :
negotiable
Price :
negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
2000sq.m/Month
Delivery Time :
20 days after receiving the deposit
Packaging Details :
Plywood case
Pixel Pitch :
6 mm
LED Type :
SMD2727
LED Encapsulation :
Nationstar
Drive Method :
1/8 scan
Brightness :
7,000 CD/m2
Max. Power :
1,000 W/m2
Cabinet Size :
768 × 768 mm
Material :
Iron, with back door
Description

Synchronization Control SMD2727 full color outdoor advertising led display Screen in public places

Quick Detail:

1. 768 × 768 mm cabinet size;
2. 8 × 4 pcs cabinets;
3. 6.144 × 3.072 m screen size;
4. 1024 × 512 pixels in total;
5. Meanwell power supply with CE/CB/UL;
6. Nationstar LED.

Detail Description:

This is composed with Nationstar LED, SMD2727, about 7,000 nits (testing with luminance colorimeter);
It is equipped with Meanwell RSP-320-5 power supply, CE/UL/CB certified;
Each cabinet is equipped with 2 pcs power supplies, 2 pcs cooling fans, 1 pc receiving card.

Application:

This outdoor LED screen is installed for outdoor video advertising in public places.

Specifications:

Model

PH6

LED Type

SMD2727

LED

Nationstar

PCB, mask, base cover

New Light

Resolution

W 1024 × H 512 pixels

Module Size

W 192 × H 192 mm

Cabinet Weight

23 kg/pc

Material

Iron waterproof cabinet with back door

Cabinet Size

W 768 × H 768 mm

Min. Viewing Distance

6 m

Driving Mode

1/8 scan constant current

Luminance

7,000 nits

View angle

120 degrees

Power Supply

88~294 VAC

Brand

Meanwell

Control Card

Novastar

Warranty

2 years

Synchronization Control SMD2727 full color outdoor advertising led display Screen in public places
