6 mm Outdoor Advertising LED Display, SMD2727 Outdoor Nationstar LED Screen
6 mm Outdoor Advertising LED Display, SMD2727 Outdoor Nationstar LED Screen
6 mm Outdoor Advertising LED Display, SMD2727 Outdoor Nationstar LED Screen
6 mm Outdoor Advertising LED Display, SMD2727 Outdoor Nationstar LED Screen
6 mm Outdoor Advertising LED Display, SMD2727 Outdoor Nationstar LED Screen
6 mm Outdoor Advertising LED Display, SMD2727 Outdoor Nationstar LED Screen
6 mm Outdoor Advertising LED Display, SMD2727 Outdoor Nationstar LED Screen
6 mm Outdoor Advertising LED Display, SMD2727 Outdoor Nationstar LED Screen
Specifications
Brand Name :
Dreamway
Model Number :
P6
Certification :
CE,ROHS
Place of Origin :
China
MOQ :
negotiable
Price :
negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
2000sq.m/Month
Delivery Time :
20 days after receiving the deposit
Packaging Details :
Plywood case
Type :
PH6
LED Type :
SMD2727
LED Encapsulation :
Nationstar
PCB :
1.6 mm thickness
Cabinet :
Iron, with back door
Cabinet Size :
768 x 768 mm
Cabinet Weight :
23 kg/pc
Power and Signal Connector :
Linko
Description

6 mm Outdoor Advertising LED Display, SMD2727 Outdoor Nationstar LED Screen

Quick Detail:

1. 6.144 x 3.072 m screen size;
2. 32 x 16 pcs LED modules in total per screen;
3. 4 x 4 pcs LED modules per cabinet;
4. 768 x 768 mm cabinet size;
5. 1024 x 512 pixels in total;
6. Auto brightness control.

Detail Description:

Each board is composed with 8 x 4 pcs cabinets, with each 768 x 768 mm;

Each cabinet is equipped with 2 pcs Meanwell RSP-320-5 power supplies, 2 pcs cooling fans;
Power box is equipped, with 30 KW, including OBO lightning arrester.

Application:

This is installed for outdoor fixed advertising on building, pillar based, ground, etc.

Specifications:

Pixel Pitch

6 mm

LED Type

SMD2727

LED Encapsulation

Nationstar

PCB

New Light, 1.6 mm thickness

LED Module Pixel

W 32 × H 32 dots

LED Module Size

W 192 × H 192 mm

Cabinet

Iron waterproof cabinet with back door

Cabinet Size

W 768 × H 768 mm

Screen Size

W 6.144 × H 3.072 m

Screen Resolution

W 1024 × H 512 pixels

Driving Method

1/8 scan constant current

Luminance

7,000 nits with testing by luminance colorimeter

View angle

120 degrees

Power Supply

Meanwell, CB/CE/UL standard

Power Box

30 KW

Video Processor

HDMI, VGA, DVI input signal

Power and Signal Connector

Linko

6 mm Outdoor Advertising LED Display, SMD2727 Outdoor Nationstar LED Screen

PH6 mm Outdoor LED Display, Outdoor LED Video Wall, Outdoor LED Display Advertising
