960mm x 960 mm Cabinet PH10 Outdoor Advertising LED Display with EPISTAR LED
960mm x 960 mm Cabinet PH10 Outdoor Advertising LED Display with EPISTAR LED
960mm x 960 mm Cabinet PH10 Outdoor Advertising LED Display with EPISTAR LED
960mm x 960 mm Cabinet PH10 Outdoor Advertising LED Display with EPISTAR LED
960mm x 960 mm Cabinet PH10 Outdoor Advertising LED Display with EPISTAR LED
960mm x 960 mm Cabinet PH10 Outdoor Advertising LED Display with EPISTAR LED
960mm x 960 mm Cabinet PH10 Outdoor Advertising LED Display with EPISTAR LED
960mm x 960 mm Cabinet PH10 Outdoor Advertising LED Display with EPISTAR LED
Specifications
Brand Name :
Dreamway
Model Number :
P10
Certification :
CE,ROHS
Place of Origin :
China
MOQ :
negotiable
Price :
negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
2000sq.m/Month
Delivery Time :
20 days after receiving the deposit
Packaging Details :
Plywood case
Model :
PH 10
Cabinet Size :
960 × 960 mm
Material :
Steel, with back door
Power Supply :
Chuanglian
Power :
5V 40A
Screen Resolution :
576 × 288 pixels
Max. Power :
750 W/sq.m
Brightness :
6500 CD
Description



960 by 960 mm Cabinet PH10 Outdoor Advertising LED Display with EPISTAR LED


Quick Detail:

1. EPISTAR LED chip;
2. W 36 × H 18 pcs LED modules in total;
3. W 6 × H 6 pcs LED modules per cabinet;
4. 150 mm thickness;
5. Chuanglian brand power supply;
6. Novastar controller.


Detail Description:

There are 648 pcs LED modules totally for this project, 36 by 18 pcs;
Each cabinet is composed with 6 by 6 pcs LED modules;
The power supply is Chuanglian brand, 5V 40A, 4 pcs power supplies in a cabinet.


Application:

Outdoor full color LED display is used for outside advertising, to show video, animation, picture, text, etc.


Specifications:

Type

PH 10

LED Chip Brand

Epistar

LED Type

DIP346

Resolution

10,000 dots/sq.m

Module Pixel

W 16 × H 16

Module Size

W 160 × H 160 mm

Cabinet Size

W 960 × H 960 × D 150 mm

Cabinet Color

Black

Cabinet Material

Steel waterproof cabinet with back door

Drive Mode

1/4 scan constant current

Brightness

More than 7,500 nits/sq.m

Refresh Rate

≥800Hz

Cabinet Weight

About 48 kg/pc

Driving IC

MBI5024

Viewing Angle

110 degrees

Life Span

＞100,000 hours

Power Supply Voltage

220V / 60HZ

Controller

NovaStar

Package

Plywood case

Waterproof Grade

IP65


960mm x 960 mm Cabinet PH10 Outdoor Advertising LED Display with EPISTAR LED

Outdoor Advertising LED Display Screen, Outdoor Full Color Advertising LED Display, RGB LED Display Outdoor Advertising
