Aluminum Rental Soccer Stadium Perimeter LED Screen PH 10 Soft LED Module
Aluminum Rental Soccer Stadium Perimeter LED Screen PH 10 Soft LED Module
Aluminum Rental Soccer Stadium Perimeter LED Screen PH 10 Soft LED Module
Aluminum Rental Soccer Stadium Perimeter LED Screen PH 10 Soft LED Module
Aluminum Rental Soccer Stadium Perimeter LED Screen PH 10 Soft LED Module
Aluminum Rental Soccer Stadium Perimeter LED Screen PH 10 Soft LED Module
Aluminum Rental Soccer Stadium Perimeter LED Screen PH 10 Soft LED Module
Aluminum Rental Soccer Stadium Perimeter LED Screen PH 10 Soft LED Module
Specifications
Brand Name :
Dreamway
Model Number :
P10
Certification :
CE,ROHS
Place of Origin :
China
MOQ :
negotiable
Price :
negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
2000sq.m/Month
Delivery Time :
20 days after receiving the deposit
Packaging Details :
Flight case
Description



Aluminum Rental Soccer Stadium Perimeter LED Screen PH 10 Soft LED Module


Quick Detail:

1. Aluminum waterproof cabinet;
2. Soft rubber LED module;
3. Hanging beam equipped;
4. YZK power and signal connector;
5. 6×6 pcs LED modules per cabinet;
6. 700 W max power consumption.


Detail Description:

This perimeter LED display could be used also as rental type, aluminum cabinet made, including locks;
LED display module is soft, in case of damage of LED display, and cover above the cabinet;
NovaStar controller used for operation, with above 1200 HZ refresh rate.


Application:

Such perimeter LED display is installed in soccer stadium for ads, could be used for rental ad also.


Specifications:

Type

PH 10

LED Composition

1R1G1B

LED Chip

EPISTAR

Resolution

10,000 dots/sq.m

LED Module Pixel

W 16 × H 16

LED Module Size

W 160 × H 160 mm

Cabinet Material

Aluminum waterproof cabinet, with locks at the two sides and support at the back

Driving Method

1/4 scan constant current

Brightness

≥7500 nits/sq.m

Refresh Rate

1200~4000 Hz

Out of Control Dot Rate

＜0.0001

Earth Leakage Current

＜2mA

MTBF

＞5,000 hours

Life Span

＞100,000 hours

Power Supply

110V/60HZ and 220V/50HZ interchangeable

Brand

Meanwell

Controller

NovaStar

Package

Flight case with wheels


Aluminum Rental Soccer Stadium Perimeter LED Screen PH 10 Soft LED Module
