PH 10 Big Outdoor Advertising LED Display with 5020 IC 6500 nits Luminance
PH 10 Big Outdoor Advertising LED Display with 5020 IC 6500 nits Luminance
PH 10 Big Outdoor Advertising LED Display with 5020 IC 6500 nits Luminance
PH 10 Big Outdoor Advertising LED Display with 5020 IC 6500 nits Luminance
PH 10 Big Outdoor Advertising LED Display with 5020 IC 6500 nits Luminance
PH 10 Big Outdoor Advertising LED Display with 5020 IC 6500 nits Luminance
PH 10 Big Outdoor Advertising LED Display with 5020 IC 6500 nits Luminance
PH 10 Big Outdoor Advertising LED Display with 5020 IC 6500 nits Luminance
Specifications
Brand Name :
Dreamway
Model Number :
P10
Certification :
CE,ROHS
Place of Origin :
China
MOQ :
negotiable
Price :
negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
2000sq.m/Month
Delivery Time :
20 days after receiving the deposit
Packaging Details :
Plywood case
Pixel Pitch :
10 mm
Screen Size :
5.76 × 2.88 m
Cabinet Size :
960 × 960 mm
Cabinet Quantity :
6 × 3 pcs
LED Module Size :
160 × 160 mm
Drive Method :
1/4 scan
Luminance :
6500 nits/sq.m
Controller :
NovaStar
Description



PH 10 Big Outdoor Advertising LED Display with 5020 IC 6500 nits Luminance


Quick Detail:

1. 4 pcs power supplies per cabinet;
2. 4 pcs fans each cabinet;
3. 5.76 by 2.88 m each LED display;
4. 960 by 960 mm per LED box;
5. Novastudio operation software;
6. About 42 kg/pc cabinet.


Detail Description:

Each display size is 5.76 by 2.88 m, 5 units such size LED display to be installed in Israel;
Per cabinet is with pixel of 96 by 96 dots, with 1 pc receiving card, high refresh rate;
YZK brand power and signal connector for easy assembling and disassembling.


Application:

This outdoor advertising LED display would be installed for outdoor street advertising.


Specifications:

Pixel Pitch

PH 10

LED Chip

Epistar

LED Type

DIP346

Resolution

10,000 dots/sq.m

LED Module Pixel

W 16 × H 16

LED Module Size

W 160 × H 160 mm

Cabinet Size

W 960 × H 960 × D 150 mm

Module Quantity Per Cabinet

W 6 × H 6 = 36 pcs

Cabinet Material

Steel waterproof cabinet with back door

Driving Method

1/4 scan constant current

Brightness

More than 6,500 CD/sq.m

Refresh Rate

≥1200Hz

Cabinet Weight

About 42 kg/pc

Driving IC

JXI5020

Viewing Angle

100 degrees

Min. View Distance

10 m

Power Supply

220V / 60HZ

Brand

Chuanglian

Controller

Novastar

Package

Plywood case


PH 10 Big Outdoor Advertising LED Display with 5020 IC 6500 nits Luminance
