Specifications
Brand Name :
Dreamway
Model Number :
P10
Certification :
CE,ROHS
Place of Origin :
China
MOQ :
negotiable
Price :
negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
2000sq.m/Month
Delivery Time :
20 days after receiving the deposit
Packaging Details :
Plywood case
LED Chip :
EPISTAR
Pixel Pitch :
10 mm
LED Type :
DIP346
Cabinet Size :
960 × 960 mm
Cabinet Resolution :
96 × 96
Weight :
42 kg/pc
Control Card :
NovaStar
Package :
Plywood Case
Description



10000 dots P 10 Outdoor Advertising Display , 160mm x 160 mm LED Module


Quick Detail:

1. 36 × 18 = 648 pcs LED modules per LED display;
2. 576 × 288 = 165,888 pixels per display screen;
3. 96 × 96 = 9,216 dots per cabinet;
4. NOVASTAR controller;
5. 1 pc cabinet with 1 pc receiving card;
6. 2 pcs cabinets in 1 pc plywood case.


Detail Description:

This type is EPISTAR LED chip, with more than 6,500 nits/sq.m;
Equipped with YZK / LINKO power and signal connector, good quality, easy assemble and disassemble;
The main network cable is totally outdoor waterproof, 30 m per display.


Application:

This outdoor advertising LED display is to be installed in Israel for outdoor advertising.


Specifications:

Model

P 10 mm

LED Chip

Epistar

LED Type

DIP346

Resolution

10,000 dots/sq.m

LED Module Pixel

W 16 × H 16

LED Module Size

W 160 × H 160 mm

Cabinet Dimension

W 960 × H 960 × D 150 mm

Cabinet Weight

42 kg/pc

Cabinet Material

Steel waterproof cabinet with back door

Cabinet Color

Black

Brightness

More than 6,500 nits/sq.m

Refresh Rate

≥1200Hz

Drive Method

1/4 scan constant current

Drive IC

JXI5020

LED Composition

1R 1G 1B

Power Consumption (MAX)

about 700 W/sq.m

Power Supply

220V / 60HZ

Operation Software

NOVASTUDIO

Controller

Novastar

Warranty

2 years
