1R1G1B Full Color LED Display P 5 SMD3528 LED Video Processor for Church
1R1G1B Full Color LED Display P 5 SMD3528 LED Video Processor for Church
1R1G1B Full Color LED Display P 5 SMD3528 LED Video Processor for Church
1R1G1B Full Color LED Display P 5 SMD3528 LED Video Processor for Church
1R1G1B Full Color LED Display P 5 SMD3528 LED Video Processor for Church
1R1G1B Full Color LED Display P 5 SMD3528 LED Video Processor for Church
1R1G1B Full Color LED Display P 5 SMD3528 LED Video Processor for Church
1R1G1B Full Color LED Display P 5 SMD3528 LED Video Processor for Church
Specifications
Brand Name :
Dreamway
Model Number :
P5
Certification :
CE,ROHS
Place of Origin :
China
MOQ :
negotiable
Price :
negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
2000sq.m/Month
Delivery Time :
20 days after receiving the deposit
Packaging Details :
Plywood case
Model :
PH5
LED Module :
320 × 160 mm
Cabinet Dimension :
1280 × 800 mm
Depth :
105 mm
Driving Mode :
1/16 scan
Power Source :
Chuanglian
Voltage :
220V / 50HZ
Video Processor :
VMS726
Description

1R1G1B Full Color LED Display P 5 SMD3528 LED Video Processor for Church

Quick Detail:

1. 2.56 × 1.6 m screen size;

2. 1280 × 800 mm cabinet size;

3. 2 × 2 pcs cabinets;

4. 4 × 5 pcs LED modules per cabinet;

5. 4 pcs power supplies for each cabinet;

6. DVI, VGA, CV, HDMI input signals.

Detail Description:

This screen dimension is 2560 by 1600 mm, with 4 pcs LED boxes composed;

We equip video processor in this project, to achieve more input signals like HDMI, DVI, VGA, etc;

Plywood case provided to pack the goods.

Application:

This indoor full color LED display is installed in church to play text and live broadcast.

Specifications:

Model

5 mm

LED Composition

1R1G1B

LED Type

SMD3528

Total Module Quantity

W 8 × H 10 = 80 pcs

LED Module Pixel

W 64 × H 32

LED Module Size

W 320 × H 160 mm

Screen Dimension

W 2560 × H 1600 mm

Screen Resolution

W 512 × H 320

Cabinet Color

Black

Driving Method

1/16 scan constant current

Brightness

More than 1,500 nits/sq.m

Weight

about 38 kg/sq.m

Out of Control Dot Rate

＜0.0001

Earth Leakage Current

＜2mA

Control Method

Synchronization control with PC

Controller

Novastar

Power Supply

220V 60HZ

Brand

Chuanglian

Package

Plywood box

Warranty

2 years
