Specifications
Brand Name :
Dreamway
Model Number :
P16
Certification :
CE,ROHS
Place of Origin :
China
MOQ :
negotiable
Price :
negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
2000sq.m/Month
Delivery Time :
20 days after receiving the deposit
Packaging Details :
Plywood case
Description



1R 1G 1B PH 16 LED Billboard Signs OPTO / SANAN LED Video Advertising


Quick Detail:

1. Steel waterproof cabinet;
2. Max power consumption 900 W/sq.m;
3. OPTO / SAN'AN LED chip;
4. MBI5024 IC;
5. 256 × 256 mm LED module;
6. YZK brand power and signal connector.


Detail Description:

The maximum power consumption of this type is about 900 W/sq.m;
YZK power and signal connector is used, with high quality, no easy to break;
Control PC could be also equipped so that our customers could use it directly after getting the goods.


Application:

Such outdoor LED billboard is for vivid advertising on road.


Specifications:

Type

P16

LED Composition

1R1G1B

LED Type

DIP546

Resolution

3,906 dots/sq.m

LED Module Pixel

W 16 × H 16

Module Size

W 256 × H 256 mm

Cabinet Size

W 1024 × H 1024 mm

Cabinet Color

Black

Cabinet Material

Steel waterproof with back door

Drive Mode

Static scan

Brightness

More than 8000 nits/sq.m

Refresh Rate

Over 800 Hz

Drive IC

MBI5024

View Angle

110°

MTBF

＞5,000 hours

LED Life Span

＞100,000 hours

Power Supply

Meanwell

Warranty

2 years

Operation Software

NovaStudio

Package

Plywood case


1R 1G 1B PH 16 LED Billboard Signs OPTO / SANAN LED Video Advertising
