8 mm SMD3535 Led Outdoor Advertising Screen 6500 CD LINSN Controller
8 mm SMD3535 Led Outdoor Advertising Screen 6500 CD LINSN Controller
8 mm SMD3535 Led Outdoor Advertising Screen 6500 CD LINSN Controller
8 mm SMD3535 Led Outdoor Advertising Screen 6500 CD LINSN Controller
8 mm SMD3535 Led Outdoor Advertising Screen 6500 CD LINSN Controller
8 mm SMD3535 Led Outdoor Advertising Screen 6500 CD LINSN Controller
8 mm SMD3535 Led Outdoor Advertising Screen 6500 CD LINSN Controller
8 mm SMD3535 Led Outdoor Advertising Screen 6500 CD LINSN Controller
Specifications
Brand Name :
Dreamway
Model Number :
P8
Certification :
CE,ROHS
Place of Origin :
China
MOQ :
negotiable
Price :
negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
2000sq.m/Month
Delivery Time :
20 days after receiving the deposit
Packaging Details :
Plywood case
Type :
P8
LED Type :
SMD3535
Module Pixel :
32 × 16 dots
Module Size :
256 × 128 mm
Cabinet Size :
1024 × 768 mm
Weight :
32 kg/pc
Brightness :
6500 CD
Operation Software :
LEDStudio
Description



8 mm SMD3535 Led Outdoor Advertising Screen 6500 CD LINSN Controller


Quick Detail:

1. 1024 × 768 mm LED box size;
2. 4 × 6 pcs LED modules per cabinet;
3. 14 cm thickness;
4. 32 kg per cabinet;
5. Chuanglian power supply with 220V;
6. 4 pcs power supplies per LED box.


Detail Description:

It is 1024 by 768 mm per cabinet, with 3072 by 2304 mm whole screen size, 9 pcs cabinets in total;
Video processor is equipped to get more signal inputs like HDMI, VGA, DVI, etc;
LINKO power and signal connector.


Application:

This outdoor advertising LED display would be installed in India for outdoor video advertising.


Specifications:

Pixel Pitch

8 mm

LED Type

SMD3535

LED Composition

1R 1G 1B

Screen Size

W 3.072 × H 2.304 m

Screen Resolution

W 384 × H 288

LED Module Size

W 256 × H 128 mm

Cabinet Size

W 1024 × H 768 × D 150 mm

Cabinet Weight

32 kg/pc

Material

Steel waterproof cabinet with back door

Module Quantity

W 12 × H 18 = 216 pcs

Cabinet Quantity

W 3 × H 3 = 9 pcs

Refresh Rate

≥1000Hz

Driving Method

1/4 scan constant current

Brightness

6500 nits/sq.m

Viewing Angle

140 degrees

Thickness

140 mm

Power Supply

220V / 60HZ

Brand

Chuanglian

Controller

LINSN

Video Processor

HDMI, VGA, DVI, etc


8 mm SMD3535 Led Outdoor Advertising Screen 6500 CD LINSN Controller

8 mm SMD3535 Led Outdoor Advertising Screen 6500 CD LINSN Controller

P8 Outdoor Advertising LED Display, Outdoor LED Video Wall, Outdoor LED Video Display Wall
