10 mm Pixel Pitch P10 Outdoor LED Signs With Front Service Synchronous Control
10 mm Pixel Pitch P10 Outdoor LED Signs With Front Service Synchronous Control
10 mm Pixel Pitch P10 Outdoor LED Signs With Front Service Synchronous Control
10 mm Pixel Pitch P10 Outdoor LED Signs With Front Service Synchronous Control
10 mm Pixel Pitch P10 Outdoor LED Signs With Front Service Synchronous Control
10 mm Pixel Pitch P10 Outdoor LED Signs With Front Service Synchronous Control
10 mm Pixel Pitch P10 Outdoor LED Signs With Front Service Synchronous Control
10 mm Pixel Pitch P10 Outdoor LED Signs With Front Service Synchronous Control
Specifications
Brand Name :
Dreamway
Model Number :
P10
Certification :
CE,ROHS
Place of Origin :
China
MOQ :
negotiable
Price :
negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
2000sq.m/Month
Delivery Time :
20 days after receiving the deposit
Packaging Details :
Plywood case
Pixel Pitch :
10 mm
LED Chip :
EPISTAR
LED Type :
DIP346
Service Method :
Front
Cabinet Quantity :
6 pcs
Cabinet Size :
1280 × 960 mm
Brightness :
6500 nits
Controller :
NOVA
Description

10 mm Pixel Pitch Outdoor LED Signs with Front Service Synchronous Control

Quick Detail:

1. 7.68 × 0.96 m screen size;
2. 1.28 × 0.96 m cabinet dimension;
3. Steel waterproof cabinet with frame;
4. 6 pcs power supplies in a cabinet;
5. NOVASTAR controller;
6. Chuanglian brand super-thin power supply.

Detail Description:

This screen is composed with 6 pcs cabinets, P10 type, EPISTAR LED chip, 6500 nits;
Controlled with synchronization, 1 pc receiving card in each cabinet, high refresh rate;
YZK brand power and signal connector at one side.

Specifications:

Pixel Pitch

10 mm

LED Chip

EPISTAR

LED Module Pixel

W 16 × H 16

LED Module Size

W 160 × H 160 mm

Screen Size

W 7680 × H 960 mm

Cabinet Size (without frame)

W 1280 × H 960 mm

Service Way

Front

Cabinet Color

Black

Cabinet Material

Steel waterproof cabinet with frame and hydraulic lever

Drive Method

1/4 scan constant current

Brightness

≥6500 nits/sq.m

LED Module in a Cabinet

W 8 × H 6 = 48 pcs

Drive IC

JXI5020

Earth Leakage Current

＜2mA

MTBF

＞5,000 hours

Life Span

＞100,000 hours

Control Method

Synchronization with PC

Controller

NOVASTAR

Operation Software

NOVASTUDIO

Package

Plywood case

10 mm Pixel Pitch P10 Outdoor LED Signs With Front Service Synchronous Control

Front Service LED Sign, 10 mm Outdoor LED Sign Display, Advertising LED Sign
