Outdoor Video Screen Rental SMD P3.91 LED Display 500*1000mm Cabinet

Specifications

Brand Name :

Dreamway

Model Number :

P3.91

Certification :

CE,ROHS

Place of Origin :

China

MOQ :

Negotiable

Price :

Negotiable

Payment Terms :

T/T, Western Union

Supply Ability :

2000sq.m/month

Delivery Time :

20 days after receiving the deposit

Packaging Details :

flight case

Product Name :

Outdoor Video Screen Rental

Pixel Pitch :

3.91mm

Color :

Full Color

Module Size :

250×250mm

Cabinet Size :

500×1000mm

Usage :

Outdoor Advertising LED Display, Outdoor Live Events LED Screen

Application :

Stage,event show,musical show,conferences

Warranty :

1-2 Years

Description

Outdoor Video Screen Rental SMD P3.91 LED Display 500*1000mm Cabinet 3.91mm Outdoor Advertising LED Display

Quick Detail:

1. W 500 × H 1000 mm cabinet size

2. W 250 × H 250 mm LED Module Size

3. About 13 kg/pc

4. At least 1 year quality guarantee

5. Die-Casting Aluminum Cabinet (500 by 1000 mm)

Feature:

1.Multifunctional connecting,High image quality,Large viewing angle.

2. Independent waterproof structure for both cabinet & module, front proof IP65 rear proof IP54, better waterproof & dustproof effect.
3. Supporting both front & rear maintenance, quick & fast installation.
4. High brightness, gray, & refresh rate is optional, high quality image effect under sunbathing.

Application:

Outdoor LED Screen main function is to display alphanumeric, image and video source to the public, for its advantage of high

brightness, implement color, and free to assemble to a different size, and various installation method.

Product Description:

Module parameters
Technical parameters	UNIT	Parameters values
Pixel pitch	MM	PH3.91
Material		Die-casting aluminum cabinet with locks and handle
Moudle size	MM	W 250× H 250
Cabinet size	MM	W 500 × H 1000
Physical density	dot/M2	65,536
LED module pixel	DOTS	W 64 × H 64 = 4,096
Drive IC		ICN2038S
LED Encapsulation	SMD	1820
Pixel configuration		1R1G1B
Driving method		1/16 scan
Maximum power	W/M2	<800
Brightness	CD/M2	≥4000
Working temperature	°C	-20~+60
Working humidity	RH	10%~90%
Min. viewing distance	M	3
Lamp failure frequency		<0.0001
IP rating		IP 65
Controller		Novastar

P3.91 Outdoor Video Wall Moudle details:
