1500m³ / H 60m Dredging Depth Portable Suction Dredge 11.8m Overall Length
1500m³ / H 60m Dredging Depth Portable Suction Dredge 11.8m Overall Length
Specifications
Brand Name :
Leader Dredger
Model Number :
LD1500PSP
Certification :
ISO 9001
Place of Origin :
China
MOQ :
One Ship
Price :
Free Consultation
Payment Terms :
L/C, T/T
Supply Ability :
20 Pcs One Week
Delivery Time :
Peak season lead time: 1-3 months ; Off season lead time: 1-3 months
Packaging Details :
In Container Or Bulk Vessel
Discharge Pipe DIA :
300mm(14")
Mixture Capacity :
1500m³/h
Pure Sand Capacity :
450m³/h
Dredging Depth :
3-60m
Discharge Distance :
700m
Installed Power :
350kw
Description

1500m³h 60m dredging depth Portable dredge 11.8m Overall length

1. Portable Dredge

This is a very convenient dredger. The pump of the portable dredge is directly fixed by the winch. This design makes the length of the hull only 11.8m, but the dredging depth can reach 60m.
This design is very easy to transport, but because of size, protable dredge is more suitable for dredging in small ponds or small lakes.

2. Main Features:

1. Fully assembled and fully tested before delivery;
2. Simple and fast assembly and disassembly;
3. Standard design, early delivery and low price;
4. Spare parts are in stock;
5. Can be transported by road, rail or sea;
6. Reliable hydraulic system;
7. Efficient fuel consumption;
8.Single person operation;
9. Provide a variety of optional equipment

3. Leader Dredger LD1500PSP Technical Specifications

General
Type LD1500PSP
Function Sand mining

Dredging Features
Mixture capacity (approx)
 1500m³/h
Standard dredging depth(m) 3-60m
Dredging pump mode 300mm(14")
Solid capacity(approx) 450m³/h

Principal characteristics
Overall length(m) 11.8m
Breadth(m) 6m
Draught (m
 1m
Discharge distance (m)
700m

Dredge pump:
High-effiffifficiency wear-resistant pump
Mixture capacity (approx)
1500m³/h
Solid capacity(approx)
450m³/h
concentration
 30%
Moto power
250kw

Engine
Generator set (Cummins KTA19)
350kw
Total fuel consumption (approx)
69L/H

Electric system
European-brand electric system

Winche
Three Electric Drive Winches Lock dredger three Anchor
Hoisting hoist
 11kw

4. Main Part

Cummins Slient Generator Set

1500m³ / H 60m Dredging Depth Portable Suction Dredge 11.8m Overall Length

Electrict Drive High-effiffifficiency wear-resistant pump

1500m³ / H 60m Dredging Depth Portable Suction Dredge 11.8m Overall Length

Electric high-effiffifficiency winch

1500m³ / H 60m Dredging Depth Portable Suction Dredge 11.8m Overall Length

5. Our Service

1. Provide consulting and design services before sales, and provide scheme support to customers according to their working conditions and needs.

2. Suggestions on spare parts configuration according to customer's requirements

3. Provide on-site installation guidance, overall commissioning, pre-job training, tracking guidance services ( dredger master, mechanic)

4. Provide one-year after-sales service

5. Providing permanent accessories and consulting services
