All Metal Downhole Motor Drilling For Geothermal Well 178mm OD
All Metal Downhole Motor Drilling For Geothermal Well 178mm OD
All Metal Downhole Motor Drilling For Geothermal Well 178mm OD
All Metal Downhole Motor Drilling For Geothermal Well 178mm OD
All Metal Downhole Motor Drilling For Geothermal Well 178mm OD
All Metal Downhole Motor Drilling For Geothermal Well 178mm OD
Specifications
MOQ :
Negotiable
Supply Ability :
30000PCs per Year
Delivery Time :
5-15work days
Packaging Details :
According to customer needs
Model :
6LZ178x7.0-4
Drilling Fluid :
Water/Salty Water/ Oil Base Mud
Well Temperature :
Below 150℃
Application :
Coiled Tubing Drilling
Bend :
Single Bend
Standard :
API Spec 7-1
Origin :
China
HS Code :
84122910
Package :
Wood Cartons Free of Fumigation or Naked
OEM :
Available
Place of Origin :
Hebei,China
Certification :
ISO9001
Price :
Negotiable
Payment Terms :
T/T
Description

All Metal Down Hole Motor for Geothermal Well Drilling

With the well depth goes deeper and deeper the most difficult problem appears which is the high temperature. The well temperature of extreme high temperature well and geothermal well exceeds 200℃even 300℃. And the rubber parts in conventional downhole is not possible to be applied in such extreme high temperature environment. All metal power section downhole motor is designed to overcome this kind of high temperature drilling environment.

Availability of our small size downhole motor:

Downhole Motor Specification OD Bit Size Connection Lobe Stage Flow Rate RPM Output Toque Max Operating Temperature Max WOB
mm In mm In Top Bottom Lpm Gpm N.m lb-ft ℃ ℉ kN lb
9LZ43x7.0-4 43 1-11/16 48~76 1-7/8~3 1” MT 1” MT 9:10 4 80~160 20.4~40.8 170~340 270 200 400 752 6 1300
9LZ89x7.0-4 89 3-1/2 108~149 4-1/4~5-7/8 3-1/2REG 3-1/2REG 9:10 4 380~756 100~200 180~360 1350 1000 400 752 36 8000
9LZ127x7.0-4 127 5 149~200 5-7/8~7-7/8 3-1/2REG 3-1/2REG 9:10 4 380~1520 100~400 25~88 7560 5600 400 752 156 35000
6LZ178x7.0-4 178 7 213~251 8-3/8~9-7/8 4-1/2 IF/REG 4-1/2REG 6:7 4 1140~2850 300~750 90~225 12500 9200 400 752 225 50000
7LZ216x7.0-4 216 8-1/2 250~311 9-7/8~12-1/4 6-5/8 REG 6-5/8 REG 7:8 4 1514~3406 400~900 50~112 15660 11600 400 752 355 80000

All Metal Downhole Motor Drilling For Geothermal Well 178mm ODAll Metal Downhole Motor Drilling For Geothermal Well 178mm OD

All Metal Downhole Motor Drilling For Geothermal Well 178mm OD
