8 203mm Down Hole Motor For Oil And Gas Well Directional Drilling
8 203mm Down Hole Motor For Oil And Gas Well Directional Drilling
8 203mm Down Hole Motor For Oil And Gas Well Directional Drilling
8 203mm Down Hole Motor For Oil And Gas Well Directional Drilling
Specifications
MOQ :
Negotiable
Supply Ability :
30000PCs per Year
Delivery Time :
5-15work days
Packaging Details :
According to customer needs
Model :
7LZ-203-3.8-1210
Drilling Fluid :
Water/Salty Water/ Oil Base Mud
Well Temperature :
Below 150℃
Application :
Coiled Tubing Drilling
Bend :
Single Bend
Standard :
API Spec 7-1
Origin :
China
HS Code :
84122910
Package :
Wood Cartons Free of Fumigation or Naked
OEM :
Available
Place of Origin :
Hebei,China
Certification :
ISO9001
Price :
Negotiable
Payment Terms :
T/T
Description

Local aging of elastomer occurs frequently in conventional downhole motors because the elastomer thickness of conventional downhole motor is different. The elastomer are worn not evenly. That leads to a power section failure soon. This problem is solved greatly in Even Wall Thickness downhole motors. The elastomer of even wall thickness downhole motor is the same. It is worn evenly in drilling operation so it extends the working life greatly. Even wall thickness downhole motors also provide 50% more toque than conventional downhole motors and longer working life in directional well drilling.

Our even wall thickness downhole motor are able to be custom made as per the customers detailed requirements if the required size is not available in below tables.

Availability of our small size downhole motor:

Downhole Motor Specification OD Bit Size Connection Lobe Stage Flow Rate RPM Working Pressure Drop Output Toque Max Pressure Drop Max Toque Operating WOB Max WOB Output Power
mm In mm In Top Bottom Lpm Gpm MPa Psi N.m lb-ft MPa Psi N.m lb-ft kN lb kN lb KW HP
4LZ-203-6.1-950 203 8 251-311 9-7/8~12-1/4 6-5/8REG 6-5/8REG 4:5 6.1 1510-3410 399-901 97-218 14.18 2056 18190 13417 21.27 3085 27285 20125 150 33000 220 48400 415 557
7LZ-203-3.8-1210 203 8 251-311 9-7/8~12-1/4 6-5/8REG 6-5/8REG 7:8 3.8 1510-3410 399-901 62-140 8.83 1281 17686 13045 13.25 1921 26529 19568 150 33000 220 48400 259 347
7LZ-203-4.2-1190 203 8 251-311 9-7/8~12-1/4 6-5/8REG 6-5/8REG 7:8 4.2 1510-3410 399-901 56-126 9.76 1416 21790 16072 14.64 2124 32685 24108 150 33000 220 48400 288 386
