1-1/2 38mm Down Hole Mud Motor For Coiled Tubing Drilling
1-1/2 38mm Down Hole Mud Motor For Coiled Tubing Drilling
1-1/2 38mm Down Hole Mud Motor For Coiled Tubing Drilling
1-1/2 38mm Down Hole Mud Motor For Coiled Tubing Drilling
Specifications
MOQ :
Negotiable
Supply Ability :
30000PCs per Year
Delivery Time :
5-15work days
Packaging Details :
According to customer needs
Model :
5LZ38×7.0-4-360
Drilling Fluid :
Water/Salty Water/ Oil Base Mud
Well Temperature :
Below 150℃
Application :
Coiled Tubing Drilling
Bend :
Single Bend
Standard :
API Spec 7-1
Origin :
China
HS Code :
84122910
Package :
Wood Cartons Free of Fumigation or Naked
OEM :
Available
Place of Origin :
Hebei,China
Certification :
ISO9001
Price :
Negotiable
Payment Terms :
T/T
Description

1-1/2" (38mm) Down Hole Motor for Coiled Tubing Drilling

With the rapid development of coiled tubing drilling technique the downhole motor gets smaller and smaller which is applied in well drilling and repairing. Small size downhole motors used in coiled tubing are paid more and more attention on well repairing, micro bore hole drilling, side drilling and re-drilling of old well. Because the coiled tubing can not rotate in drilling small size downhole motor is one of the best choice of downhole drilling tool in coiled tubing drilling and well repairing which has been applied in such as well flushing, sand cutting and so on.

Besides the coiled tubing operation the small size downhole motor is also applied in radial drilling operation.

Availability of our small size downhole motor:

Downhole Motor Specification OD Bit Size Connection Lobe Stage Flow Rate RPM Working Pressure Drop Output Toque Max Pressure Drop Max Toque Operating WOB Max WOB Output Power
mm In mm In Top Bottom Lpm Gpm MPa Psi N.m lb-ft MPa Psi N.m lb-ft kN lb kN lb KW HP
5LZ38×7.0-4-360 38 1-1/2 43~60 1-7/8~2-3/8 1AMMT 1AMMT 5:6 4 45~90 12~24 228~457 3.2 466 81 60 4.52 655 114 84 2 440 4 880 4.8 6.6

1-1/2

1-1/2

1-1/2
