Dia 160cm Conical Rock Drilling Auger With Round Shank Chisel
Dia 160cm Conical Rock Drilling Auger With Round Shank Chisel
Dia 160cm Conical Rock Drilling Auger With Round Shank Chisel
Dia 160cm Conical Rock Drilling Auger With Round Shank Chisel
Specifications
Brand Name :
BJTUFF
Model Number :
400-3000mm or as required
Certification :
ISO9001
Place of Origin :
China
MOQ :
1 Piece
Price :
Prices are determined by quantity and model of product
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
300 Unit/Units per Month
Delivery Time :
3-5 days after payment
Packaging Details :
standard export packs -Wood case outside, plastic cases inside.
Material :
16Mn or GB-Q355B
Teeth Series :
Bullet Teeth
Color :
Black or as required
Kelly Box size :
200*200mm as usual or as your required
Application :
Rotary Drilling Rig
Product name :
Conical Rock Auger
Description

Various Models Conical Rock Drilling Auger Bucket With Round Shank Chisel

Feature:
Located by pilot, conical structure drilling into the rock；
Double cutter bears uniform force and can avoid inclined hole ;
Double spiral easy to carry soil, but single spiral is easy to dump spoil when meeting cohensive soil;
Applicable layers: pebble,mudstone,sandstone layer,medium weathered rock, bedrock；

Model List
Cutting Dia.
Spiral HIT.
Spiral Pitch
Spiral THK.
Spiral OD.
Center Tube OD.
Teeth No.
φ600
1200
600+400
30+20
550
219
15
φ800
1400
600+400
30+20
750
245
21
φ900
1400
600+400
30+20
850
245
22
φ1000
1500
600
30+20
950
245
23
φ1200
1500
600
30+30
1150
245
25
φ1500
1500
600
30+30
1450
273
32
φ1600
1500
600
30+30
1550
273
34
φ1800
1500
600
35+30
1750
273
38
φ2000
1500
600
35+30
1950
273
38
φ2200
1500
600
35+30
2150
273
40
φ2500
1500
600
35+30
2450
273
40

Remark : The length is in milimeters, weight in kilograms.

Customizable Items:


Cutting Diameter Custom : various cutting diameter based on demand, like φ620,φ850 etc.
Spiral Height Custom : design as demand such as heightening spiral to increase the efficiency for drilling more once.
Spiral Pitch Custom : adjust the spiral pitch according to different layers;
Key Component Reinforce Custom : reinforce auger to extend life cycle;
Kelly Box Custom : custom kelly box size based on the kelly bar, like 130*130, 150*150 and etc;
