Specifications
Brand Name :
KonDaSin
Model Number :
VH330
Certification :
ISO9001
Place of Origin :
Jiangsu,China
MOQ :
1 set
Price :
Contact us
Supply Ability :
5+set+per month
Delivery Time :
15 days
Packaging Details :
In 40′container with drilling tools
Name :
Excavator hydraulic vibration hammer
Application :
Pile Drilling
Power System :
Hydraulic
Type :
Pile Driver
Material :
45# Steel
Weight :
2.3t-3.5t
Description

Excavator Vibration Hammer Excavator Attachment Flexiable Control Quick Speed
Excavator Vibration Hammer Excavator Attachment Flexiable Control Quick Speed
Vibrating Pile hammer is using it’s high frequency vibration to vibrate pile body with high accelertaion to pass the vertical vibration of mechanical produce to pile which leading to changes in the soil structure around the pile,strength decrease. Soil around the piles become liquefaction to reduce frictional resistance between side of the pile and soil. Then using the excavator down force,vibrating the hammer and pile body weight to sink pile into the soil. When extracting piles,in the condition ofvibration to pull out the pile by using excavator lift force.Excitation force needed by pile driving machinery are comprehensive determined any site soil,soil condition,moisture content and type of pile,construction.

Excavator Vibration Hammer Excavator Attachment Flexiable Control Quick Speed

Module UNIT VH250 VH330 VH350 VH450
Eccentric moment NM 40 50 65 85
Frequency RPM 2800 2800 2800 2800
Excitation Force TON 36 45 58 75
Weight of Main Body KG 1500 2200 2800 3500
Operation Pressure of oil system BAR 280 280 300 300
Flow Demand for hydraulic oil system LPM 155 168 210 255
Excavator TON 18-25 30-40 40-50 40-65
Main Pile Length M 9 13 16 18

Excavator Vibration Hammer Excavator Attachment Flexiable Control Quick Speed

1.Flexiable control
2.Silence operation
3.Easy maintenance
4.Precision design
5.Reliable performance
6.Quick Speed
​7.Easy operation
Excavator Vibration Hammer Excavator Attachment Flexiable Control Quick Speed

The efficient of vibration pile method is higher than other methods. It is mainly applied to steel steet pile,steel pipe pile and long slender concrete pecast pile within 8 -15 meters. This pile driving method is the most suitable for working in sand and poorer effect in the clay which must select higher power model machines.
Excavator Vibration Hammer Excavator Attachment Flexiable Control Quick Speed
Excavator Vibration Hammer Excavator Attachment Flexiable Control Quick Speed
