Professional Wireline Drilling Core Barrel Stainless Steel For Mineral Exploration
Professional Wireline Drilling Core Barrel Stainless Steel For Mineral Exploration
Professional Wireline Drilling Core Barrel Stainless Steel For Mineral Exploration
Professional Wireline Drilling Core Barrel Stainless Steel For Mineral Exploration
Professional Wireline Drilling Core Barrel Stainless Steel For Mineral Exploration
Professional Wireline Drilling Core Barrel Stainless Steel For Mineral Exploration
Specifications
Brand Name :
KonDaSin
Model Number :
BQ, NQ, HQ and PQ
Place of Origin :
China
MOQ :
1piece
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
10000 Meter/Meters per Month
Delivery Time :
8 working days
Packaging Details :
Wooden case
Certification :
ISO9001
Name :
Wireline Double / Triple Core Barrel Assembly
Material :
Steel
Usage :
Geological Drilling
Avalilable Size :
BQ NQ NQ PQ
Standard :
DCDMA CMS GB
Length :
1.5m 3m
Advantage :
save much time while collect core sample
Packing :
Wooden Case or Carton
Description

Drilling Core Barrel Wireline Drilling Tools Deep Holes Mineral Exploration

Professional Wireline Drilling Core Barrel Stainless Steel For Mineral Exploration

Wireline drill tools can lift drill core from drill rods without picking up drilling rods and bits.All the tools include principal parts of the drill tools,over shot assembly ,drill rods.holding dog,circle wrench and etc,their advantages are higher penetration,higher core recovery ratio.Longer bit life and lower labor intensity,and the advantages get more clear with the increasing of hole depth.

This has major cost advantages when drilling deep holes for mineral exploration.

The head assembly provides: latching and pivoting spear point mechanisms to allow insertion and retrieval of the inner tube assembly, a bearing assembly to allow the inner tube to remain stationary and avoid sample damage while drilling, fluid pressure operating indications and fluid control valves.

All head assemblies incorporate a shut off valve assembly which provides a fluid pressure signal to the drill operator when the valve members are compressed, indicating a full or blocked inner tube.

Professional Wireline Drilling Core Barrel Stainless Steel For Mineral Exploration

Q Series Wireline Double Tube Core Barrels
Size Hole(mm) Core(mm) Head Thread
BQ 59.3 36.2 BQ rod box
NQ 75.2 47.6 NQ rod box
HQ 95.6 63.5 HQ rod box
PQ 122 85 PQ rod box
Q Series Wireline Triple Tube Core Barrels
Size Hole(mm) Core(mm) Head Thread
NQ3 75.2 45 NQ rod box
HQ3 95.6 61 HQ rod box
PQ3 122 83 PQ rod box

Professional Wireline Drilling Core Barrel Stainless Steel For Mineral Exploration

Available size:

International Standard:BQ NQ HQ PQ

Chinese Standard: Wireline 56, wireline 59, wireline 75, wireline 95

Professional Wireline Drilling Core Barrel Stainless Steel For Mineral Exploration

Professional Wireline Drilling Core Barrel Stainless Steel For Mineral Exploration
