High Speed Core Drilling Equipment , Wireline Drilling Tool Rods Easy Loading
High Speed Core Drilling Equipment , Wireline Drilling Tool Rods Easy Loading
High Speed Core Drilling Equipment , Wireline Drilling Tool Rods Easy Loading
High Speed Core Drilling Equipment , Wireline Drilling Tool Rods Easy Loading
High Speed Core Drilling Equipment , Wireline Drilling Tool Rods Easy Loading
High Speed Core Drilling Equipment , Wireline Drilling Tool Rods Easy Loading
Specifications
Brand Name :
KonDaSin
Model Number :
BQ, NQ, HQ and PQ
Place of Origin :
China
MOQ :
1piece
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
10000 Meter/Meters per Month
Delivery Time :
8 working days
Packaging Details :
Wooden case
Certification :
ISO9001
Name :
Core Barrel&overshot Assembly
Material :
Steel
Usage :
Geological Drilling
Avalilable Size :
BQ NQ NQ PQ
Standard :
DCDMA CMS GB
Length :
1.5m 3m
Advantage :
save much time while collect core sample
Packing :
Wooden Case or Carton
Description

High Speed Core Drilling Equipment , Wireline Drilling Tool Rods Easy Loading
High Speed Core Drilling Equipment , Wireline Drilling Tool Rods Easy Loading

We offers a complete line of single & double and triple tube core barrels, which will provide superior performance and obtain the full recovery of the sample in any application of diamond core drilling.

The series can be divided into BQ, NQ, NQ3, HQ, HQ3, PQ and PQ3 types, is very commonly used for mineral exploration for deep holes because of practical usage.

Wireline core barrels eliminate the major time consuming operation of using standard double tube core barrels – pulling, stacking and lowering drill rods each time the core barrel is full.

Wireline tube Core Barrels enable integral core recovery when drilling coal, clay bearing or highly fractured formations. The split tube retains the core sample in its received state for easier loading into sample trays or for storage and subsequent presentation to the geological.

A Overshot is available for each size of core barrel, lower on the wireline to recover the inner tube assembly containing core.

High Speed Core Drilling Equipment , Wireline Drilling Tool Rods Easy Loading
High Speed Core Drilling Equipment , Wireline Drilling Tool Rods Easy Loading

Q Series Wireline Double Tube Core Barrels
Size Hole(mm) Core(mm) Head Thread
BQ 59.3 36.2 BQ rod box
NQ 75.2 47.6 NQ rod box
HQ 95.6 63.5 HQ rod box
PQ 122 85 PQ rod box
Q Series Wireline Triple Tube Core Barrels
Size Hole(mm) Core(mm) Head Thread
NQ3 75.2 45 NQ rod box
HQ3 95.6 61 HQ rod box
PQ3 122 83 PQ rod box

High Speed Core Drilling Equipment , Wireline Drilling Tool Rods Easy Loading

1. Faster coring at greater depths

2. higher penetration

3. higher core recovery

4. longer bit life

5. lower our labor intensity

6. Good stability due to constant diameter of the drill string

High Speed Core Drilling Equipment , Wireline Drilling Tool Rods Easy Loading

Wire-line core drilling equipment is very commonly used for mineral exploration for deep holes.

High Speed Core Drilling Equipment , Wireline Drilling Tool Rods Easy Loading

High Speed Core Drilling Equipment , Wireline Drilling Tool Rods Easy Loading
