Abrasion Resistance 6 5/8" Oilfield Tubing Head for Wellhead

Product Introduction

Our tubing heads operate in working pressures of 2,000, 3,000 and 5,000 psi and test pressures of 4,000, 6,000 and 7,500 psi. Maximum slip flange load is rated to 85,000 pounds.

Bottom Connections Bolt-through flange, studded flange and clamp-hub connections are available. The type and pressure rating used must match the top flange of the previous casing spool or crossover flange. Bolt-through flange connections are the most popular and economical type of connection in certain parts of the world. Clamp-hub connections are sometimes specified, because they are much faster to make up and because they reduce the diameter and weight of the assembly when space limitations are present.

Our products have been ISO9001 certified and attained API 6A,6D,API 7,7K,and API 16A&16C approvals of American Petroleum Institute. All products are fully designed and manufactured in accordance with API,ANSI,GB(national standards)and SY(industry standards)standards.

Design Features of TR Wellhead Tubing Head

1. Made from high-strengh alloy and processed specially with heating treatment.
2. All stell tanks are welded with staintess stell for long-term anti-corrosion.
3. Designed and manufactured with reference to API 6A technical specifications.
4. Top & bottom connections and outlets per customer design requirements by either flanged or clamp connections.
5. Used for high-pressure drilling, in conjunction with flat valve for preventing blowout and connecting BOP.
6. Fit for Hydrogen sulfide H2S resistant service, manufactured with reference to NACEMR 0175 technical specifications.

Technical Data of TR Wellhead Tubing Head

Xi'an TianRui Petroleum Machinery Equipment Company Limited designs, manufactures and supplies conventional wellheads and X-mas trees of all sizes, working pressures and temperatures. The sealing performance is reliable and the service life span is long.

We have more than 10 years history in designing and manufacturing wellhead and christmas tree. The technology is in a leading position in China. We gained PR2 certificates for gate valve, choke valve and tubing head. Annual production is 5000 sets. Products have been exported to America, Saudi Arabia, India, Russia, Oman, Turkmenistan, Kazakhstan, Venezuela, etc.

Competitive Advantages

1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.
