Specifications
Brand Name :
TR Solids Control
Model Number :
TR-5LZ
Certification :
API & ISO Certificate
Place of Origin :
Xi'an China
MOQ :
1 pc
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
6000 pcs per month
Delivery Time :
25 days
Packaging Details :
Pallet or wooden case
Size :
3 1/2"-17 1/2"
Thread :
2 3/8" Reg
Material :
Carbide
Use :
Well Drilling, Energy & Mining
Processing Type :
Forging/Casting
Color :
Blue, green, white
Model :
7LZ120*5.0L-7
Lobe :
5:6
Description

Lockheed API 7LZ120*5.0L-7 Drilling Downhole Motor

Product Descrption

Drilling Mud Motor is a kind of downhole drilling tool powered by mud. The mud from mud pump enters motor by way of bypass valve, and a pressure drop between motor inlet and outlet created, such pressure drop will drive the motor rotator to rotate, and transmit the torque and rotary speed to bit by universal shaft and transmission shaft. The downhole motor property mainly depends upon its property parameters. This product uses the high and new technology of coating to avoid coating off of rotors resulted from the traditional technology. Its strength and life are greatly improved. It is applicable to directional drilling horizontal drilling, composite drilling, cluster wells, sidetrack wells and well workover etc.


We are specialized in designing & manufacturing mud motor, motor manufacturing, testing and maintenance equipment. The stable quality and high performance of our mud motors, spare parts and equipment have been effectively proven by customers in Russia, India, Iran and China.

Characterstics of Oilfield Downhole/Mud Motor

  1. Better hole deviation control.
  2. Increased rate of penetration.
  3. Reduction in wear and tear of the swivel, Kelly, and rotary drives.
  4. Reduction in drill string failure rate.
  5. Reduction in fuel cost, since compared to rotary drilling, less energy is required to power a downhole motor.

Technical Data Sheet of Our Downhole/Mud Motor

Item No
Hole Size

Input

Flow

Rate

Pressure

Loss

Bit

Speed

Working

Torque

Delay

Dynamic

Torque

Output

Power

Max

Drilling

Weight

Joint Thread Length
Unit mm In L/S Mpa r/min N.m N.m KW KN In In mm
5LZ73×7.0 83-121 3 1/4-4 3/4 2-4 3.2 80-160 615 1077 5.8-11.5 25 2 3/8REG 2 3/8REG 3423
9LZ89×7.0 105-143 4 1/8-5 5/8 3-8 3.2 147-392 504 882 8.64-23 30 2 7/8REG 2 7/8REG 2911
5LZ95×7.0 114-150 4 1/8-5 7/8 5-12 3.2 140-320 710 1240 10.5-25 40 2 7/8REG 2 7/8REG 3920
5LZ120×7.0 152-200 6-7 7/8 8-16 3.2 80-180 1850 3200 23-47 106 3 1/2REG 3 1/2REG 5039
5LZ165×7.0V 245-244 8 1/8-9 5/8 18-30 3.2 111-167 4440 7770 57.6-86.4 160 4 1/2REG 4 1/2REG 7408
5LZ165.5×7.0V 215-244 8 1/8-9 5/8 18-30 4.0 120-180 5135 8987 72-108 180 4 1/2REG 4 1/2REG 7748
5LZ172×7.0V 215-244 8 1/8-9 5/8 18-30 4.0 120-180 5135 8987 72-108 180 4 1/2REG 4 1/2REG 7391
5LZ172.5×7.0V 215-244 8 1/8-9 5/8 20-35 4.0 115-180 6452 11299 86.4-151.2 200 4 1/2REG 4 1/2REG 8031
7LZ172.5×7.0V 215-244 8 1/8-9 5/8 20-35 4.0 75-180 6527 11420 59.5-108.6 160 4 1/2REG 4 1/2REG 8631
5LZ185×7.0 215-244 8 1/8-9 5/8 20-35 4.0 184 5436 8154 80-140 240 4 1/2REG 6 1/2REG 8120
5LZ185.5×7.0 215-244 8 1/8-9 5/8 20-35 4.0 173 5939 8908 80-140 240 4 1/2REG 6 1/2REG 8120
5LZ197×7.0 244-311 9 1/8-12 5/8 20-40 3.2 61-122 14118 14118 57.6-115.2 240 5 1/2REG 6 5/8REG 7998
5LZ197.5×7.0 244-311 9 5/8-12 1/4 20-40 4.0 85-160 12640 12640 72-144 260 5 1/2REG 6 5/8REG 8598
7LZ203×7.0 244-311 9 5/8-12 1/4 20-40 3.2 70-155 12289 12289 57.6-126.7 240 5 1/2REG 6 5/8REG 7798
5LZ203.5×7.0 244-311 9 5/8-12 1/4 20-40 4.0 70-155 8778 15362 72-158.4 260 5 1/2REG 6 5/8REG 8598
5LZ244×7.0 311-445 12 1/2-17 1/2 50-75 3.2 91-136 15124 26468 144-216 360 6 5/8REG 7 5/8REG 8635
7LZ244.5×7.0 311-445 12 1/2-17 1/2 50-75 4.0 91-136 18905 33085 180-270 450 6 5/8REG 7 5/8REG 9235

Carbide Lockheed Well Drilling Downhole Motor Forging

Xi'an TianRui Petroleum Machinery Equipment Company Limited is a professional manufacturer of cementing tools and other petroleum equipment in China. We are the first-class supplier of resources market of SINOPEC and CNPC. Our products include cement tools, PDC drilling bits, Wellheading tools, Mud pumps and their acceossries. They are exported to Russia, America, Middle East, South America, Southeast Asia, Central Asia , African, Australia,Europe etc. Our company is willing to cooperate and make common progress with friends at home and abroad with first-class products, first-class service and reasonable prices.

We hope to cooperate with more customers for mutual development and benefits. We welcome potential buyers to contact us. Xi'an TianRui Petroleum Machinery Equipment Company Limited was founded in 2010, in Xi'an City, Shaanxi Province. Its business covers drilling and workover rigs spare parts, solids control equipment, wellhead equipment and tools, oiflied fishing tools , downhole tools, drilling strings, OTCG and other equipments related with petroleum. Strictly abide by ISO9001 quality system certification and API standard. At the same time, we build one new workshop for the forging and casting production for the oilfield tools, We can offer the precision forging and casting production according to the customer's drawing. Our engineers help the customer's design and drawing, then make production for the customers.

Competitive Advantages


1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.
