ND45S DTH Hammer Borewell Drilling Hammers
ND45S DTH Hammer Borewell Drilling Hammers
ND45S DTH Hammer Borewell Drilling Hammers
ND45S DTH Hammer Borewell Drilling Hammers
Specifications
Brand Name :
shitan
Model Number :
ND45
Place of Origin :
hebei china
MOQ :
10set
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
100000/day
Delivery Time :
5-7day
Packaging Details :
Wooden box
Certification :
ISO
Advantage :
high quality and factory prices
Color :
According to your requirements
Machine Type :
Drilling Tool
Wxternai diameter :
99.5mm
Bit Shank :
K40 Wooke40
Hole range :
105-$130
Connection Thread :
AP12 3/8*REG
Recommended rotation speed :
22-35r/min
lmpact rate at :
1.7Mpa" 31Hz
Working Pressure :
1.2-2.5Mpa
Description

ND45S DTH Hammer Borewell Drilling Hammers Of Drilling Rig Components

Introduction To DTH Hammer

We have all series of drilling equipment and drilling tools for water well or mining
By using high-quality raw materials, utilizing advanced craft technologies and imposing strict quality inspection, the product range covers:DTH drilling rig,DTH drill tools(dth hammers and dth bits),drill pipes, underground water detector, shank adapters and coupling sleeves, drilling rig, air compressor and spare parts for drill equipment.

High Without Foot Hammer ND45S DTH Hammer Water Well Drilling Tool Borewell Drill Accessory

DTH (Down-the-hole) Hammer And Bits

Impactor parameters To DTH Hammer

High Air Pressure DTH hammers(3''-12''):

1.ND(DHD Shank) series high air pressure DTH hammer includes:DHD3.5,DHD340,DHD350R,DHD360,DHD380,DHD1120

2.QL series high air pressure DTH hammer includes:QL40,QL50,QL60,QL80

3.SD series high air pressure DTH hammer includes:SD4,SD5,SD6,SD8,SD10,SD12

4.NUMA series high air pressure DTH hammer includes:NUMA100,NUMA120,NUMA125

5.COP series high air pressure DTH hammer includes:COP44,COP54,COP64,COP84

Length(Without bit)
Weigth(Without bit)
Wxternai diameter
BitShank
Hole range
Connection Thread
791mm 31kg 99.5mm K40
Wooke40		 105-$130 AP12 3/8*REG
Working Pressure
lmpact rate at 1.7Mpa
Recommended rotation speed
Air consumption
1.0mpa 1.8Mpa 2.4Mpa
1.2-2.5Mpa 31Hz 22-35r/min 5m'/min 9m'/min 14m3/min

Advantages of DTH Hammer


1. The structure is very simple, the component reliability is good, the impactor life is long, the maintenance is simple, and the cost is low.
2. Low impact energy loss and high impact frequency can improve lifting force and reliability.
3. With its stable and reliable, energy-saving and high-efficiency, it is favored and praised by many customers at home and abroad.
It is one of the most advanced impactors in the world.

ND45S DTH Hammer Borewell Drilling Hammers
