Quarrying Prospecting Three Cone 7 7/8Inch Rock Drilling Bit
Quarrying Prospecting Three Cone 7 7/8Inch Rock Drilling Bit
Specifications
Brand Name :
ShiTan
Certification :
ISO9001
Place of Origin :
China
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
L/C, D/A, T/T, Western Union
Supply Ability :
20000pcs/Year
Delivery Time :
Within 7-12 days
Packaging Details :
Standard export package
Model Number :
Geological Prospecting
Type :
three cone bit
Machine Type :
Drilling Tool
Use :
Well Drilling
Material: :
Diamond Material
Application :
Geological Prospecting
Color :
ar your demand
Description
High Quality Factory Manufacturing Rock Drilling Bit PDC Diamond Drilling Bit

Introduction of Diamond Drilling Bit:

Our drilling bit have a very good drilling performance and long life time. Different diameters and taper degrees are available to suit different applications in mining, quarrying etc.

Drilling bit size from 90mm-450mm.

If you are interest in our machine, please inform us the drilling bit size that you like

main parameters

Specifications of Diamond Drilling Bit


bit size(in)		 bit size(mm) bit type
6 152.4 517G,537G,617G,637G
6 1/2 165.1 517G,537G
7 7/8 200.0 517G,527G,547G,617G,627G,637G
8 1/2 215.9 437G,447G,517G,537G,617G,627G,637G
9 1/2 241.3 437G,517G,537G,547G,617G
9 5/8 244.5 437G,517G,537G,547G,617G
9 7/8 250.8 437G,517G,537G,547G,617G
12 1/4 311.1 437G,517G,537G,617G,627G,637G
17 1/2 444.5 517G,537G,617G,627G,637G

Features of Diamond Drilling Bit:

The down-hole drill is a kind of drill which is used in conjunction with the down-hole impactor.

It is widely used in mining/quarry/hydro-power engineering/drilling well/side column support, etc.

It is divided into: low pressure down-hole drill, medium and high wind pressure down-hole drill.

The drill is used in combination with the drill hammer, which has the characteristics of straight drilling, fast speed and deep drilling.

Characteristics of Diamond Drilling Bit :

During the follow-up drilling of complex formations, the selected drilling parameters should be based on the principles of low speed, low feed pressure, and high return air speed.

During the construction operation, the hardness and looseness of the rock in the drilled formation should be selected. Factors such as water content and water content control the drilling speed. When drilling encounters formations with particularly loose or large fractures, it is especially necessary to reduce the feed speed and feed pressure, and repeatedly carry out slag removal and hole cleaning.
