350m Deep Water Well Hydraulic Crawler Drill Machine Equipment Big Steel Borehole
350m Deep Water Well Hydraulic Crawler Drill Machine Equipment Big Steel Borehole
350m Deep Water Well Hydraulic Crawler Drill Machine Equipment Big Steel Borehole
350m Deep Water Well Hydraulic Crawler Drill Machine Equipment Big Steel Borehole
Specifications
Brand Name :
ShiTan
Model Number :
ST-350
Certification :
ISO,CE,SGS,TUV,BV
Place of Origin :
China
MOQ :
1 set
Price :
workable
Payment Terms :
T/T, Western Union
Supply Ability :
2000 sets per year
Delivery Time :
10-15 days
Packaging Details :
customized packed or normal packing
Drilling Rig Name :
350 Meters Deep Water Well Steel Crawler Mounted Borehole Drilling Machine
Hole Diameters :
105-350mm
Place Of Origin :
China (Mainland)
Model Numbe(m) :
ST 350
Drilling Depths :
350 meters
Warranty :
1 year
Color :
Yellow,Red
OEM :
Customized
Crawler :
Steel Crawler
Truck Mounted :
Optional
Tech Support :
Video Support
Description

350 Meters Deep Water Well Steel Crawler Mounted Borehole Drilling Machine

ST 350 Borehole Drilling Machine Descrption

ST 350 Pneumatic Drilling Rig Machine is is equipped with powerful hydraulic rock drills that offer high penetration rates, reliability, and excellent fuel economy.It is a high efficiency and multi-functional down the hole water well drilling equipment, It can be used to drill water well, agrecultural irrigation well, geothermal well and other type well holes. It is sepcial suitable for mountain area and rock stratum water sourcing project.

ST 350 Borehole Drilling Technical Information

Drilling Rig Model
ST 350
Drilling depth
350meters
Dia.hole
φ140 - 325mm
Advance Length one time
6.6m
Working pressure
1.7-3.3MPa
Air consumption
17-35m³/min
Length of rod
1.5m,2m,3m, 6m
Dia. Of rod
φ89,φ102,φ114
Lifting power
24T
Rotation torque
6200-85000N.m
Rotation Speed
55-115r/min
Diesel Engine
Yuchai
Engine Power
92Kw/2200rpm
Travelling speed
0-2.5 Km/h
Climb capacity
30°
Weight
9000kgs
Dimension
5900x2000x2850mm
Application
Complicated geological conditions: Rock, Mud, Sand etc.
ST 350 Borehole Drilling Applications
it is mainly applicable to industrial and civil drilling, geothermal drilling, has the advantages of compact structure, fast advancing, mobile and flexible wide application region etc., It is especially suitable for water intake in mountainous and rocky strata.

What aspects should we pay attention to in the drilling process of water well drilling rig

Bit plays a very important role in the drilling of water well drilling rig, but the quality of a bit directly affects the efficiency and quality of water well drilling. Therefore, in the selection process, we should pay attention to the selection and use of lower bit. When we are operating the drill bit, we must pay attention to several aspects in order to better production and operation.

350m Deep Water Well Hydraulic Crawler Drill Machine Equipment Big Steel Borehole

350m Deep Water Well Hydraulic Crawler Drill Machine Equipment Big Steel Borehole

350m Deep Water Well Hydraulic Crawler Drill Machine Equipment Big Steel Borehole

350m Deep Water Well Hydraulic Crawler Drill Machine Equipment Big Steel Borehole350m Deep Water Well Hydraulic Crawler Drill Machine Equipment Big Steel Borehole
