API SPEC 8C PSL1 Truck Mounted Drilling Rig Swivel Common And Double Duty
API SPEC 8C PSL1 Truck Mounted Drilling Rig Swivel Common And Double Duty
Specifications
Model Number :
SL160,SL225
Certification :
API
Place of Origin :
CHINA
Payment Terms :
L/C, T/T
Packaging Details :
WOODEN BOX
Description

Swivel

Swivel has two categories, common swivel and double duty swivel. Double duty swivel is common swivel combined with spinner.
The company' s swivel matches the API SPEC 8C PSL1 products standards.
It received the API certification issued by the American Petroleum Institute and allow to use API monogram.
Washpipc packing set assembly adopts casscttc structure.
It can be exchanged quickly without disassemble rotary hose and gooscncck.
May matching 3LP and 4LP internal or external thread hose conncction thread.
The company can also manufacture low temperature resistant swivel according to customer's requirement.
Common swivel consists of swivel bail,shell. Support. gooseneck. central pipe . master bearing . joint other parts.
The lower end conncctcd with kclly stcni by REG thread. The swivel bail is hang on the hook.
Gooscncck and rotary hose can conncctcd by REG thread conncction or union conncction (Under normal circunistanccs, the CH125 swivel not welded thread joint, other types of swivel welded 4LP external thread).
API SPEC 8C PSL1 Truck Mounted Drilling Rig Swivel Common And Double Duty
型号type CH125 SL135 SL160 SL170 SL225 SL315 SL450
最大静载荷 kN
Max.Dead Load		 1250 1350 1600 1700 2250 3150 4500
最高转速r/min
Max.Revolution		 300
最大工作压力 Mpa
Max.Working Pressure		 21 35
鹅颈管中心线与垂线夹角
Angle between the gooseneck central line and vertical line		 15°
接头下螺纹
Lower thread		 6⅝REG-LH
中心管通径 mm
Bore Size of Central Pipe		 Φ68 Φ60 Φ70 Φ75
冲管通径 mm Φ70 Φ57.15 Φ70 Φ75
提环弯曲处断面 mm
Fractured surface at bail bend		 116×90
R50		 R67.5 115×95
R63		 125×115
R60		 70×120
R60		 180×140
R70		 180×165
R75
提环弯曲半径
Bail bend radius		 R105 R115 R120
外形尺寸(长×宽×高) mm
overall dimension		 2100×660×620 2290×650×640 2470×790×680 2725×840×785 2970×1040×980 3010×1040×980 3040×1110×1095
质量 weight 625 777 1000 1250 2500 2700 2900
