Truck mounted drilling rig with mud pump or air compressor
Truck mounted drilling rig with mud pump or air compressor
Specifications
Place of Origin :
China
Brand Name :
TS
Model Number :
TST-150
MOQ :
1set
Delivery Time :
3months
Payment Terms :
T/T L/C
Certification :
ISO9001
Description

If you need our products, contact or check on line.

Or email me directly:3123981177@163.com

TST-150 truck-mounted drilling rig is the new designed rig used for petroleum, coal and minerals prospecting and sampling in complex terrain formation area. It is mounted on WTC5225TSM 6*6 off-road truck chassis. Power takes from chassis engine. The drilling rig uses hydraulic driving. It can carry out air drilling, mud drilling normal circulation function.

  1. Main technical parameters:

Max drilling depth

Mud drilling: 150m, air drilling: 80m

Drilling method

Mud drilling, air drilling

Drilling tools

Drill bits (dia)

Ф114mm

Drilling pipe (DiaXLength)

Ф60×4500mm

Power swivel

Output torque

3400N.m

Output rev. scope

0-160 r/min

Pull-up & pull-down system

Max pull-up force

32kN

Feed rate

0～0.4m/s

Max Pull-up rate

1.7m/s

Hydraulic system

Oil pump rev.

1600r/min

Working pressure

Rotating

17MPa

Pull-down

12MPa

Mud pump

Pressure

3MPa

Flow rate

300L/min

Screw air compressor

Pressure

1.2 MPa

Displacement

12.5 m3/min
  1. Truck information:
  1. WTC5225TSM 6*6 desert off-road truck chassis
  2. Color: cab is yellow, Frame and bridge are black
  3. Drive type: 6*6
  4. Performance parameter:

Max. speed: 70km/h

Max. speed in desert: 20km/h

Min. turning diameter: ≤22m

Max. clamping slope: 50%

Max. clamping slope in desert: 30%

Brake distance: ≤9m (speed: 30km/h)

Angle of approach/angle of away : 35°/30°

Min. Ground clearance of machine: 400mm

If you are also interested in other drilling rigs http://www.drillingrigts.com/

Contact Ms.Ann http://www.drillingrigts.com/contact.html
