Mechanical Downhole Tester Valve For Drill Stem Testing Tools 2991mm 15000psi
Mechanical Downhole Tester Valve For Drill Stem Testing Tools 2991mm 15000psi
Mechanical Downhole Tester Valve For Drill Stem Testing Tools 2991mm 15000psi
Mechanical Downhole Tester Valve For Drill Stem Testing Tools 2991mm 15000psi
Specifications
Brand Name :
ZZ TOP OIL TOOLS
Model Number :
Mechanical Tester Valve
Certification :
ISO, API
Place of Origin :
China
MOQ :
1 set
Price :
USD 1-10000/set
Payment Terms :
L/C, T/T, D/P
Supply Ability :
10 set/month
Delivery Time :
30-50 days
Packaging Details :
Pollywood
Product :
Mechanical Downhole Tester Valve
Application :
Drill Stem Testing Service
Type :
Mechanical Operate Type
Size :
5 inch
Working Pressure :
15000psi
Connection :
IF, EUE , CAS
Working Condition :
Oil & Gas & H2S service
Working Temperature :
Up to 425oF
Description

Mechanical Downhole Tester Valve For Drill Stem Testing Valve

Mechanical tester valve is a kind of downhole tester valve used in oil & gas well testing service. The mechanical tester valve is used to open and close the well by lifting and lowering the drill pipe (or tubing) to control the ball valve of the tester valve. The mechanical tester valve is closed while the tool is running in hole. When the tester valve reached the predetermined depth, J-slot mandrel will move up and down by applying the weight of workstring, and the transposition lug can rotate freely, then it will move along the travel of index groove. The workstring is lifted or set down one time, the position of J-slot mandrel will change one time, like this, the ball valve can be opened and closed finally. Above movement can be repeated many times as required.


Technical parameter of LPR N Valve

Size 127.5mm(5”)
ID 57mm
Length 2991mm
Working Pressure 105Mpa
Ball valve Differential pressure 70Mpa
Burst Pressure 140Mpa
Shear pin quantity 4pcs
Working Temperature NACE MR0175,Above 175F
Service -29oC~204oC
Connection Thread 3 1/2” IF or CAS


Mechanical Downhole Tester Valve For Drill Stem Testing Tools 2991mm 15000psi Mechanical Downhole Tester Valve For Drill Stem Testing Tools 2991mm 15000psi
