Belt Type Fruit Squeezing Machine Pineapple / Apple / Orange Juice Squeezer
Belt Type Fruit Squeezing Machine Pineapple / Apple / Orange Juice Squeezer
Belt Type Fruit Squeezing Machine Pineapple / Apple / Orange Juice Squeezer
Belt Type Fruit Squeezing Machine Pineapple / Apple / Orange Juice Squeezer
Belt Type Fruit Squeezing Machine Pineapple / Apple / Orange Juice Squeezer
Belt Type Fruit Squeezing Machine Pineapple / Apple / Orange Juice Squeezer
Belt Type Fruit Squeezing Machine Pineapple / Apple / Orange Juice Squeezer
Belt Type Fruit Squeezing Machine Pineapple / Apple / Orange Juice Squeezer
Specifications
Brand Name :
beyond
Model Number :
BY-SGX
Certification :
CE/ISO9001
Place of Origin :
China
MOQ :
1 set
Price :
negotiation
Supply Ability :
50 pcs per month
Delivery Time :
35-60 working days
Packaging Details :
standard package
Name :
belt type squeezer
Material :
stainless steel
Voltage :
according to customer local voltage
Power consumpiton :
energy saving type
Warranty :
12 months
Sea Port :
Shanghai
Description

Fruit squeezing machine belt type squeezer pineapple squeezer apple squeezer

Belt Type Fruit Squeezing Machine Pineapple / Apple / Orange Juice Squeezer

Usage: mainly used on the apple,pear and strawberry etc.

Composed of machine, automatic control cabinet, arc net filter and spraying rod etc.

It is widely used in the solid and liquid separation procedure in fruit and vegetable juicing and industrial production flow. It has such characteristic as saving energy, automatic and continuous working as well as high juicing rate.

Technical parameter

Model Capacity(T/H) Power(kw)

External dimension

(mm)

 Belt size(mm)
DYJ-5

≤5(T/H)

 3/21.37 4000×2000×2505 11800×800
DYJ -10 ≤10(T/H) 4/22.37 5000×2500×2505 14320×1200
DYJ -15 ≤15(T/H) 4/22.37 5400×2880×2505 17000×2000
DYJ -20 ≤20(T/H) 5.5/39.87 5400×3380×2505 17000×2500


Belt Type Fruit Squeezing Machine Pineapple / Apple / Orange Juice Squeezer

Belt Type Fruit Squeezing Machine Pineapple / Apple / Orange Juice SqueezerBelt Type Fruit Squeezing Machine Pineapple / Apple / Orange Juice Squeezer

Quotation of 5T/H mango & plum concentrated cloudy juice processing line
　 　 　 Part 1: technical process equipment quotation list 　 　 　
Flow NO Name Model Specification Unit Qty Manufacturer
A Fresh fruit washing unit 　 　 　 　 　
A-1 clapboard elevator 5T/h SUS304 frame,stainless steel clapboard, by frequency controller 20~100RPM,conveyer chain is made of antisepsis material Size:5000*800*500mm motor power:1.5kw PCS 1 BEYOND
A-2 brush washer 5T/h material is SUS304, size of the machine is 3000×1250×1850, imported transducer, with manual fruit pusher,at bottom with spraying device for tap water spraying,motor power:1.5kw PCS 1 BEYOND
A-3 air-blow surfing washer and sorting machine 5T/h stainless steel centrifugal pump ; oxygen pump; speed can be adjustable,size of elevator and sorting roller is φ51, sorting table with guardrail, platform is made of stainelss steel anti-skidding Checkered plates Size:6500*1000*1500 motor power:3.7kw PCS 1 BEYOND
A-4 clapboard elevator 5T/h SUS304 frame,stainless steel clapboard, by frequency controller 20~100RPM,conveyer chain is made of antisepsis material Size:7500*800*500mm motor power:2.2kw PCS 1 BEYOND
　 Subtotal: 　 　 　 　 　
B mango/plum pulping unit 　 　 　 　 　
B-1 plum Destoner 5T/H SUS304 frame,speed is adjustable by transducer,rubber roller diameter is 295mm, Blade roller diameter is 298mm, Size:1320*1106*1300mm motor power:4kw PCS 1 BEYOND
B-2 crushing machine 5T/H material is 304,it is composed by feed hopper,side cap,body,principal axis,bearing pedestal,motor,frame,discharge hopper,ect. PCS 1 BEYOND
B-3 Plum seed
re-washer		 5T/H SUS305 frame,speed is adjustable by transducer,Size:1500*650*1310 motor power:7.5kw PCS 1 BEYOND
B-4 Mango Destoner 5T/H SUS304 frame,speed is adjustable by transducer,rubber mover plate,with brush,Size:1800*910*2050,power:18.5kw PCS 1 BEYOND
B-5 screw conveyer for fruit core 　 made of SUS304 stainless steel, diameter of the screw is 300mm,U shape,length:3000mm,motor power:3kw PCS 1 BEYOND
B-6 temporary storage tank 1000L SUS304,single layer,CIP spraying ball, at bottom with flange connected outlet,with high/low level probe,4 adjustable legs PCS 1 BEYOND
B-7 screw pump 10T/H transducer adjust the speed, pressure at outlet is 0.6Mp,stainless steel rotor,food grade rubber stator. PCS 1 BEYOND PARTNER
B-8 platform for destoner 　 mild steel supporter, on surface with stainless steel checkered plate,double floor structure, dimension is 5000mm×3000mm×5000mm,water drainage in central,stainless steel handrail and staircase PCS 1 BEYOND
B-9 tubular heater 5T/H SUS304. Tubular heating, with imported steam reducing valve system, temperature is automatic controled, with thermometer at outlet PCS 1 BEYOND
B-10 single stage pulping machine 5T/H SUS304,frequency control of motor speed,960-1350rpm,stainless steel mesh screen,Size:1760*800*1500,motor power 15kw PCS 1 BEYOND
B-11 refiner 5T/H SUS304,stainless steel net hole ,variable frequency speed control,with adjustable outlet pressure PCS 1 BEYOND
B-12 screw conveyer for fruit core 　 made of SUS304 stainless steel, diameter of the screw is 300mm,U shape,length:3000mm,motor power:3kw PCS 1 BEYOND
B-13 temporary storage tank 1000L SUS304,single layer,CIP spraying ball, at bottom with flange connected outlet,with high/low level probe,4 adjustable legs PCS 1 BEYOND
B-14 screw pump 10T/H transducer adjust the speed, pressure at outlet is 0.6Mp,stainless steel rotor,food grade rubber stator. PCS 1 BEYOND PARTNER
B-15 platform for pulping machine 　 mild steel supporter, on surface with stainless steel checkered plate,double floor structure,dimension is 3000mm×2500mm×5000mm,water drainage in central,stainless steel handrail and staircase. PCS 1 BEYOND
　 Subtotal: 　 　 　 　 　
C evaporator and concentrating unit 　 　 　 　 　
C-1 buffer storage tank 3000L material is SUS304 stainless steel, with PU isolation, cone top, outlet at bottom with flange connected,sealed manhole,ladder,high/low level probe, sample valve, top mounted standing agitator, anti-eddy plate at bottom, digital indicator thermometer, CIP spraying ball, adjustable legs PCS 2 BEYOND
C-2 centrifugal pump 10T/H sanitary food grade, mechanical seal,ABB motor,pump head is 36m PCS 1 BEYOND
C-3 double effects forced circulation evaporator 2.5T/H SUS304 material,full-auto PLC control, UK imported steam reduction and adjusting valve system, imported temperature sensor, differential pressure controller,use tower water for cooling PCS 1 BEYOND
C-4 batch storage tank 5000L material is SUS304 stainless steel, single layer, digital show thermometer,sample valve,airtight manhole, ladder, high/low level sensor, standing type off-side agitator, anti-eddy plate, CIP cleaning ball, adjustable supporters PCS 2 BEYOND
C-5 rotary pump 3~5T/H SUS304,use food grade rubber as gasket, inside is mirrow polished, frequency controled PCS 1 BEYOND
　 Subtotal: 　 　 　 　 　
D Sterilization and filling system 　 　 　 　 　
D-1 tube-in-tube sterilizer 1.5T/H SUS304 stainless steel, tube-in-tube type,full-auto PLC controlled, cooling by tower water, UK imported sprirax sarco steam reducing and adjusting system, sterilization temperature is 110℃,60S PCS 1 BEYOND
D-2 degassing machine 1.5T/H Full-automatic control,frequency converted material pump,combine with sterilizer,vaccum degass pump,differential pressure sensor SET 1 BEYOND
D-2 aseptic drum filler 1.5T/H sterilized by steam, auto-control, double filling heads PCS 1 BEYOND PARTNER
　 Subtotal: 　 　 　 　 　
CIP system 　 　 　 　 　
E-1 semi-autmatic cip system 2T×3 external of CIP liquid storage tank is SUS304 stainless steel,inner is SUS316L,volume of CIP acid/alcali tanks are 2000L , with coil tubes inside of tanks for steam heating the CIP liquid, temperature is auto controled, two cleaing circuit, USA acid/alcali adding system, with small troley for acid/alcali concentrate storage barrel, one centrifugal pump(20T/h,pump head 36m) SET 1 BEYOND
R CIP return pump 20T/H food sanitary grade, self-priming, mechanical seals SET 2 BEYOND
　 Subtotal: 　 　 　 　 　
total equipment price 　 　 　 　 　
project installation and others 　 　 　 　 　
F-1 product piping system National standard include CIP pipes, product piping system, valves, meters in the main workshop, SMS standard, include installation material for CIP system SET 1 BEYOND
F-2 non-product system National standard include all steam piping, cold water piping, tap water and compressed air piping, include the insulation for the pipes SET 1 BEYOND
F-3 electric cabinets National standard include all the electric control boxes in the main workshop, and also include the closets in the local site(made of stainless steel),include electric control box for the CIP system SET 1 BEYOND
F-4 electric distributing system National standard include the electric cable and bridges, cables, and control system, design a master control box in central, with separate control box at exact point to control exact processing part, prepare reserved button for future additional use SET 1 BEYOND
F-5 installation and commissioning cost 　 installation and commissioning on the equipments from seller's company, the buyer take charge of the round way traffic cost from china to buyer's factory,pay for the accomadation for the seller's engineers during the installation and commissioning period, in addition pay USD 100 per day for each engineer SET 1 BEYOND
F-7 Freight and packing 　 send to shanghai port SET 1 BEYOND
