Specifications
Brand Name :
Shanghai Beyond
Model Number :
BY-PM
Certification :
ISO9001/CE/SGS
Place of Origin :
China
MOQ :
1set
Supply Ability :
50 Sets Per Year
Delivery Time :
3months
Packaging Details :
Standard export wood case and metal frame support
Power consumption(Kw) :
energy saving type, about 100-500kw,
Efficiency :
High Efficiency
Control :
Automatic Control
Warranty: :
12 Months After Commissioning
Solution :
Turn Key Project
Operator needed :
About 4-18persons
After Sales Service :
Engineers Are Available For Serving Machinery Overseas
Description

6000LPH Automatic Control Coconut drink Processing Plant / Fruit coconut milk Processing Plants

6000LPH Automatic Control Fruit Processing Equipment For Coconut Milk Drink

Brief Introduction of Dairy Processing Plant

Brand Name: Shanghai Beyond
Model Number: BY-PM
Capacity 5-300TPD
Raw material

Fresh cow milk, buffalo milk, goat milk, camel milk

or milk powder, or both mixed
End product

Fresh milk, pasteurized milk,

standardized pasteurized milk
Shelf life 5-7days (keep at 4 ℃ )
Final product fat (%)

Semi-skimmed or double toned milk (1.5%);

Full cream(3% or 6%); Toned milk(3%)
SNF 8.5%(min)
Main material for machines SUS304 or SUS316
Package for end product Aseptic large bag in drum/ glass bottle/PET bottle, Roof type carton box/ brick shape carton
Certification: ISO9001/CE/SGS
Place of Origin: China
Manufacturer history More than 10years

6000LPH Automatic Control Fruit Processing Equipment For Coconut Milk Drink

Description:

Shanghai beyond machinery co., ltd is specialized in supplying various kinds of milk processing line, including the pasteurized milk, UHT milk, flavored milk, yoghurt, cheese and butter, cream, condensed milk etc.

Shanghai Beyond can supply complete turnkey projects for customers, integrating with designing, equipment manufacturing, to installation and commissioning and also training the operators.

Pasteurized milk process: milk transporting, milk filtering and collection; cooling and storaging, cream separation, pasteurization, homogenization, degassing, and filling.

Specifications:

1 A Coconut extraction unit 　 　
2 A-1 Coconut meat Balance tank 200L SUS304 stainless steel material, single layer, big open cover, round cylinder, adjustable round legs 1
3 A-2 Screw pump 3T/H The part touched with product material is SUS304, square flange inlet outlet, with spiral propeller, food grade rubber stator, round flange outlet, frquency converted motor 1
4 A-3 Coconut milk Extractor 1T/H The main part of the equipment adopts SUS304, and the discharge quantity of waste is adjustable, speed is frequency converted adjustable 3
5 A-4 Balance tank 500L SUS304 stainless steel material, single layer, 1
6 A-5 Centrifugal pump 5T/H SUS304 stainless steel, 36 meter lift, mechanical seal 1
7 A-6 Vibrating Screen 4T/H vibrating type of screen, used for coffee liquid and solid separating, continious type, with deslagging and liquid discharging function, 1
8 A-7 Balance tank 200L SUS304 stainless steel material, single layer, big open cover, round cylinder, electricode type high and low liquid level meter, adjustable round support legs 1
9 A-8 Centrifugal pump 5T/H SUS304 stainless steel for product contacting part, 36 meter lift, mechanical seal 1
10 A-9 Plate cooler 4T/H SUS304, NBR seal ring, one time temperature reducing from 65-8℃, Glycol aqueous solution as cooling medium 1
11 A-10 Platform 　 SUS304, stainless steel pattern plate, handrail, ladder, centralized drainage,size 4000*2500*2000mm 1
12 　 control cabinet 　 SUS304 cabiet frame, Schneider electrical components, Danfoss frequency convertor 1
13 B Coconut milk pasteurization & storage unit 　 　
14 B-1 Buffer tank 10000L SUS304, 3 layers tank, miller jacket, ice water cooling ,PU insulation, 15° conical seal at top, off-center vertical agitator, 36rpm, frequency control, sealed manhole, product inlet, central CIP cleaning ball, 360 ° rotatig, breather, roung cyliner, inner layer 3mm, jacket thickness 2mm, out clading 2mm, digitall thermometer, electictrode type high and low liquid level meter, ladders, 25° bottom seal head, pull rod valve bottom discharge, adjustable round legs 1
15 B-2 Centrifugal pump 5T/H SUS304 stainless steel, 36 meter lift, mechanical seal 1
16 B-3 Plate pasteurizer 4000L/H Inlet temperature -----8°C; sterilzing temperature ----- ( 90°C /30S) ; Outlet temperature ----- 8°C
Discription of machine:
(1) full-auto control, three stages plate type, material is coconut milk.
(2) product contacting parrs are made of SUS3104 stainless steel;
(3) with self CIP washing system;
(4) Temperature control system includ: UK Spirax Sarco steam reduce valve, regulate valve, trap water valve, German JUMO temperature transmitter, German Burkert ice water control valve;
(5) product system: material balance tank with cleaning ball and level transmiter, plate heater exchanger, sanitary centrifugal pump, GEA/APV pnumatic valve with proximity switch, etc.
(6) SUS304 stainless steel electric control cabinet, with Simence PLC touch screen, digital recorder, Schneider electrical element, Danfoss frequency converter, etc.
(7) Stainless steel square pipe frame, with adjustable legs
(8) Total power about 9KW, consumption of steam is 100kg/H, ice water consumption is 10T/H		 1
17 B-4 Chilled tank 10000L SUS304, 3 layers tank, miller jacket, ice water cooling ,PU insulation, 15° conical seal at top, off-center vertical agitator, 36rpm, frequency control, sealed manhole, product inlet, central CIP cleaning ball, 360 ° rotatig, breather, roung cyliner, inner layer 3mm, jacket thickness 2mm, out clading 2mm, digitall thermometer, electictrode type high and low liquid level meter, ladders, 25° bottom seal head, pull rod valve bottom discharge, adjustable round legs 2
18 B-5 Centrifugal pump 5T/H SUS304 stainless steel, 36 meter lift, mechanical seal 1
19 B-6 CIP returning pump 20T/H SUS304 stainless steel for product contacting part, 24 meter lift, mechanical seal 1
20 　 control cabinet 　 SUS304 cabiet frame, Schneider electrical components, Danfoss frequency convertor 1
21 　 Subtotal 　 　 　
22 C
CIP Unit		 　 　
23 C-1 CIP system 4*2T Four tanks, single circulation, Semi-auto CIP, double layers insulation tank, tank material SUS316L stainless steel, acid tank,alkali tank and hot water tank with stirrer, high & Low liquid level alarm system, Spirax Sarco temperature auto control, JUMO temperature sensor, Shanghai YUAN brand progress pump 1 piece, 20T/H, pumping lift 36M, 100L concentrated acid & alkali tank which material is SUS316L, The USA imported pneumatic diaphragm pump two pieces, 100L preparation tank for sanitizing solution which material is SUS316L, two dosing pump. 1
24 C-2 Refrigerator 80TR 80 CT , water cooling type, ice water outlet at -2℃( 20% glycol solution), with ice water storage pool, circulation pump, coolig tower. 1

Features and advantages:

1. Processing capacity can be ranged from 2T/Day to 1000T/Day.

2. High standard design, manufacture and project installation requirements, which guarantee the first-class finish products in the dairy processing line.

3. PLC control the whole production line, saving labor force and facilitate production management.

6000LPH Automatic Control Fruit Processing Equipment For Coconut Milk Drink

QUOTATION FOR 1000L/H PASTEURIZED MILK PRODUCTION LINE
NO. FLOW NO. NAME SIZE MAIN TECHNOLOGY PARAMETER UNIT QTY MANUFACTURER
1 A MILK RECEIVING AND STORAGE UNIT 　 　 　
2 A-1 milk pump Q=10T/h SUS304 stainless steel,pump lift 24M,mechanical seal pcs 1 BEYOND
3 A-2 electronic scale 　 maximum weighing 1000KG pcs 1 BEYOND
4 A-3 milk weighing tank V=300L made of SUS304 stainless steal,single layer,product feeded in through 40 mesh filter net,CIP cleaning ball pcs 1 BEYOND
5 A-4 milk acceptor V=500L SUS304 stainless steel,single layer,CIP cleaning ball pcs 1 BEYOND
6 A-5 milk pump Q=10T/h SUS304 stainless steel,pump lift 24M,mechanical seal pcs 1 BEYOND
7 A-6 twin piping filter Q=10T/h SUS304 stainless steel,two pipe,Stainless Steal Filter Element 100 Mesh pcs 1 BEYOND
8 A-7 chilling tank 4000L SUS304 stainless steel,alveolate jacket,attached with compressor,temperature automatic control pcs 2 BEYOND
9 A-8 milk pump Q=3T/h SUS304 stainless steel,pump lift 24M,mechanical seal pcs 1 BEYOND
10 　 Subtotal A: 　 　 　 　 　
11 B HOMOGENIZING/PASTEURIZING UNIT 　 　 　
12 B-1 plate type pasteurizer 1T/h SUS304 stainless steel, plate type, inlet temperature 4℃, pasteurizing temperature 85℃, holding tube 15S for milk ,outlet temperature 4℃, PID temperature auto control, hot water heating ,include milk balance tank, milk pump, plate heat exchanger, pipes and valves, frame and support, electrical control box etc pcs 1 BEYOND
13 B-2 cream seperator 1T/h fullauto control,auto residue discharge pcs 1 BEYOND
14 B-3 high pressure homogenizer 1T/h 25MPa,(starting box included) pcs 1 BEYOND
15 　 Subtotal B 　 　 　 　 　
16 C FILLING UNIT 　 　 　
17 C-1 buffer tank V=1000L SUS304 stainless steel,heat insulated,conical head,airtight manhole, breather valve,digital readout thermometer,anti-eddy baffle,supporters with adjustable feet pcs 1 BEYOND
18 C-2 Plastic bag filling machine 　 3000 b/h,250ml/b pcs 1 BEYOND
19 C-3 high level platform 　 SUS304,3500*3000*2000 pcs 1 BEYOND
20 　 Subtotal C: 　 　 　 　 　
21 D CIP UNIT 　 　 　
22 D CIP system Q=5t/h SUS304, union type CIP system,0.8T*3,electrical heating pcs 1 BEYOND
23 R-1~3 return pump Q=20T/h SUS316L stainless steel, pump lift 24M,Mechanical Seal pcs 3 BEYOND
24 　 Subtotal D: 　 　 　 　 　
25 E AUXILIARY EQUIPMENT 　 　 　
26 E-1 refrigerator unit 　 air-cooled compressor,with fron as chilling medium,20000Kcal,with ice water pool and pump pcs 1 CHINA
27 E-2 hot water boiler 　 electrical heating, 20000 kcal/h,hot water output at 90 deg C, include circulation water pumps pcs 1 CHINA
28 E-3 air compressor Q=1m³/min srew type air compressor, with air storage tank and cold drier pcs 1 CHINA
29 E-4 soft water system 2.5T/H raw water tank (2m³), sand filter, carbon filter, softener, safety filter, soft water tank(2m³), centrifugal pumps etc pcs 1 CHINA
30 E-5 cold room 　 cool with freon,working at 5℃,size: 6*4*3.3m,insulation wall thickness 4" pcs 1 CHINA
31 　 Subtotal E: 　 　 　 　 　
32 Total price for equipments 　 　 　
33 F INSTALLATON UNIT 　 　 　
34 F-1 stainless piping system 　 including CIP systemand all product pipe line ,SMS standard,￠63,￠51,￠38 set 1 BEYOND
35 F-2 power piping system 　 power pipe line ,without heat insulation set 1 BEYOND
36 F-3 electric controlling box 　 control box of all equipments,customer connect the electic cable to the electric controlling box of Beyond company set 1 BEYOND
37 F-4 electric installation material 　 electric installation material of all equipments set 1 BEYOND
38 F-5 installation and commissioning cost 　 domestic mounting and debugging of all machines offered by Beyond, buyer supply installatin tools and consumable items (if out of china,the buyer should take charge of the traffic fee and also the room and board,and $100 per person per day for subsidy) set 1 BEYOND
39 F-6 domestic freight and incidental cost 　 TO SHANGHAI PORT set 1 BEYOND
40 F-7 export package cost 　 carbon steel frame or wood case set 1 BEYOND
41 　 subtotal: 　 　 　 　 　
