Specifications
Brand Name :
beyond
Model Number :
BY-S
Certification :
CE/ISO9001
Place of Origin :
China
MOQ :
1 set
Price :
negotiation
Supply Ability :
50 pcs per month
Delivery Time :
35-60 working days
Packaging Details :
standard package
Name :
Spiral Conveyors
Material :
stainless steel
Voltage :
according to customer local voltage
Power consumpiton :
energy saving type
Warranty :
12 months
Application :
used for fruit conveying
Description

Stainless Steel Vegetables Fruit Processing Equipment With Spiral Conveyors

Fruit processing machines Spiral Conveyors Manufacturer for fruit and vegetables

Introduction

The horizontal stainless steel screw conveyor includes simplified characters (simplified design includes "U" shaped opening or cover and "O" shaped seal), screw conveyor shaft, end cover, power rotating device and other components.

The equipment is made of high-quality stainless steel, with simple structure and stable and reliable operation. It is widely used for horizontal or inclined transportation of various dry and wet materials.

In order to prevent raw materials (such as apples, pears and other fruits) from being damaged by the blades during transportation, we welded stainless steel around the conveying blades.

Stainless Steel Vegetables Fruit Processing Equipment With Spiral Conveyors

Model Description Transportation capacity

Suggested power

(kw)
Line speed Capacity
LXSS-U150

Outer shell and the spiral is made of SUS304 stainless steel, speed can is step-less adjustable

 50-112rpm 4-8(m³/H) 2-5m 0.75
6-10m 1.5
11-15m 2.2
LXSS-U200 50-100rpm 7-14(m³/H) 2-5m 1.5
6-10m 3
11-15m 4
LXSS-U250 45-90rpm 13-24(m³/H) 2-5m 2.2
6-10m 4
11-15m 5.5
16-20 7.5
LXSS-U300 40-80rpm 16-32(m³/H) 2-5m 3
6-10m 5.5
11-15m 7.5
16-20 11
LXSS-U350 36-72 rpm 26-52(m³/H) 2-5m 4
6-10m 7.5
11-15m 11
16-20 15
LXSS-U400 36-72rpm 30-60(m³/H) 2-5m 5.5
6-10m 11
11-15m 15
16-20 18.5

Stainless Steel Vegetables Fruit Processing Equipment With Spiral ConveyorsStainless Steel Vegetables Fruit Processing Equipment With Spiral ConveyorsStainless Steel Vegetables Fruit Processing Equipment With Spiral Conveyors

Stainless Steel Vegetables Fruit Processing Equipment With Spiral Conveyors

This equipment is a machine that uses the reducer to drive the spiral rotation to promote the material to achieve the purpose of conveying. The utility model has the advantages of simple structure, small cross-sectional area, convenient closed transportation, multi-point feeding or unloading, etc.

♦ Shell form: "O" type or "U" type;

♦ Spiral: no axis, single axis or multi axis;

♦ According to the different flow direction of materials, the following five feeding and discharging methods can be selected.

Stainless Steel Vegetables Fruit Processing Equipment With Spiral Conveyors

Model and parameters

Effective width: 200-400mm
Lifting angle: ≤45°
Single machine drive limit length: 1000-10000mm
Conveying speed: maximum 27m/min (adjustable)
Motor power: 0.37/0.55/0.75/1.1/1.5 /2.2Kw
