Feature:
1. Heavy duty design with load capacity of 500kg-1000kg
2. All 201 stainless structure, including wheel frames and bolts.
3. Silent casters: two swivels and two rigid
4. Widely used in medicine factory, food factory, supermarket and various plants
5. Materia SUS304 is available.
Specification:
Model | Capacity (kg) | Net weight (kg) | Platform size (mm) | Platform height(mm) | Handle height(mm) | Wheel size(mm) |
LF2436 | 500 | 23.7 | 610*915 | 215 | 840 | 125*50 |
LF2448 | 500 | 28 | 610*1220 | 215 | 840 | 125*50 |
LF3048 | 500 | 30.5 | 760*1220 | 215 | 840 | 125*50 |
LF3060 | 500 | 35.5 | 760*1525 | 215 | 840 | 125*50 |
LF3672 | 500 | 44.5 | 915*1830 | 215 | 840 | 125*50 |
MF2436 | 1000 | 24.7 | 610*915 | 240 | 865 | 150*50 |
MF2448 | 1000 | 29 | 610*1220 | 240 | 865 | 150*50 |
MF3048 | 1000 | 31.5 | 760*1220 | 240 | 865 | 150*50 |
MF3060 | 1000 | 36.5 | 760*1525 | 240 | 865 | 150*50 |
MF3672 | 1000 | 45.5 | 915*1830 | 240 | 865 | 150*50 |
NF2436 | 600 | 31.5 | 610*915 | 280 | 905 | 200*50 |
NF2448 | 600 | 35.5 | 610*1220 | 280 | 905 | 200*50 |
NF3048 | 600 | 38 | 760*1220 | 280 | 905 | 200*50 |
NF3060 | 600 | 43 | 760*1525 | 280 | 905 | 200*50 |
NF3672 | 600 | 52 | 915*1830 | 280 | 905 | 200*50 |
