LS80 LS150 Mini Winch Stacker With Removable Platform Capacity 150Kg
LS80 LS150 Mini Winch Stacker With Removable Platform Capacity 150Kg
LS80 LS150 Mini Winch Stacker With Removable Platform Capacity 150Kg
LS80 LS150 Mini Winch Stacker With Removable Platform Capacity 150Kg
LS80 LS150 Mini Winch Stacker With Removable Platform Capacity 150Kg
LS80 LS150 Mini Winch Stacker With Removable Platform Capacity 150Kg
LS80 LS150 Mini Winch Stacker With Removable Platform Capacity 150Kg
LS80 LS150 Mini Winch Stacker With Removable Platform Capacity 150Kg
LS80 LS150 Mini Winch Stacker With Removable Platform Capacity 150Kg
LS80 LS150 Mini Winch Stacker With Removable Platform Capacity 150Kg
LS80 LS150 Mini Winch Stacker With Removable Platform Capacity 150Kg
LS80 LS150 Mini Winch Stacker With Removable Platform Capacity 150Kg
Specifications
Brand Name :
Sinolift
Model Number :
LS
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
5000 sets/mouth
Delivery Time :
15 days
Packaging Details :
Sandard Export Package
Product Name :
LS80 LS150 Mini Winch Stacker With Removable Platform Capacity 150Kg
Capacity :
150Kg
Load Centre :
250mm
Lifting Height :
1100mm
Straddle Leg Height :
85mm
Min. Fork Height :
70mm
Fork Length :
500mm
Platform Size :
500X530X90mm
Over Adjustable Fork Width :
132-520mm
Overall Dimension :
865X550X1470mm
Net Weight :
52Kg
Description

Feature:

1.Robust, lightweight, steel construction.
2.Easy to maneuver with its two rigid wheels and two locking swivel wheels. extremely easy to use.
3.Cable winch lifting system with full cable housing.
4.Removable platform for increased versatility, and it is also a standard accessory.
5.Handle length on the hand crank may be adjusted to increase or decrease lifting/lowering speeds.

Specification:

Model LS80 LS150
Capacity (kg) 80 150
Load Centre (mm) 250 250
Lifting Height (mm) 1100 1100
Straddle Leg Height (mm) 85 85
Min. Fork Height (mm) 70 70
Fork Length (mm) 500 500
Individual Fork Width (mm) 50 50
Platform Size (mm) 500x530x90 500x530x90
Over Adjustable Fork Width (mm) 132-520 132-520
Effort Force with Load (N) 82 106
Load Wheel (mm) Ø100x30
Steering Wheel (mm) Ø100x30
Overall Dimensions (mm) 865x550x1470 830x580x1475
Net Weight (kg) 52 62
Important: Forks MUST be in Max. fork width position when fit platform on two forks.
