Specifications
Brand Name :
Sinolift
Model Number :
DG1500E
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
5000 sets/month
Delivery Time :
15 days
Packaging Details :
Sandard Export Package
Product Name :
DG2000A Mechanical Clamping Single Eagle Grip Forklift Drum Grabber Loading Capacity 500kg X4
Capacity :
500kgX4
Straddle inner Width :
680mm
Staddle outline Width :
990mm
Foks leg (length*width) :
150X55
Straddle Length :
900mm
Overall Size :
2190X1080X850mm
Load Center :
1150mm
Grab Min. Height :
525mm
Grab Max. Height :
750mm
Net Weight :
137kg
Warranty :
1 year
After Service :
On-line service,Spare parts
Description

Feature:

1. Single Eagle-Grip automatic clamping mechanism for handling steel & plastic drums in high volume applications.

2. Clamping mechanisms are completely mechanical, requiring no hydraulic or electrical connections.

3. Replaceable soft wear-resistant protective cushion effectively protects drums and absorbs vibration.

4. Positive action jaws insure safe transporting of drums without damage to drum chimes.

5. Lift truck operators to install/remove the attachment in seconds without any tools.

6. Fork mounted models can handle 1, 2, 3 or 4 drums simultaneously.

7. Quick adjustable heads allow pickup of various drum heights.

Specification:

Model 　 DG2000A
Capacity kg 500X4
Net Weight kg 137
Overall Size mm 2190X1080X850
Load Center mm 1150
Grab Min. Height mm 525
Grab Max. Height mm 750
Grab Middle Height mm 675--600
Foks leg (length X width) mm 150X55
Straddle inner Width mm 680
Staddle outline Width mm 990
Straddle Length mm 900
