DG1080A Drum Carriers Automatic Clamping Mechanism Drum Type Loading Capacity 1080Kg
DG1080A Drum Carriers Automatic Clamping Mechanism Drum Type Loading Capacity 1080Kg
DG1080A Drum Carriers Automatic Clamping Mechanism Drum Type Loading Capacity 1080Kg
DG1080A Drum Carriers Automatic Clamping Mechanism Drum Type Loading Capacity 1080Kg
DG1080A Drum Carriers Automatic Clamping Mechanism Drum Type Loading Capacity 1080Kg
DG1080A Drum Carriers Automatic Clamping Mechanism Drum Type Loading Capacity 1080Kg
DG1080A Drum Carriers Automatic Clamping Mechanism Drum Type Loading Capacity 1080Kg
DG1080A Drum Carriers Automatic Clamping Mechanism Drum Type Loading Capacity 1080Kg
DG1080A Drum Carriers Automatic Clamping Mechanism Drum Type Loading Capacity 1080Kg
DG1080A Drum Carriers Automatic Clamping Mechanism Drum Type Loading Capacity 1080Kg
DG1080A Drum Carriers Automatic Clamping Mechanism Drum Type Loading Capacity 1080Kg
DG1080A Drum Carriers Automatic Clamping Mechanism Drum Type Loading Capacity 1080Kg
Specifications
Brand Name :
Sinolift
Model Number :
DG1080A
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
5000 sets/month
Delivery Time :
15 days
Packaging Details :
Sandard Export Package
Product Name :
DG1080A Drum Carriers Automatic Clamping Mechanism Drum Type Loading Capacity 1080Kg
Capacity :
1080Kg
Overall Size :
1080X1520X850mm
Straddle inner Width :
670mm
Staddle outline Width :
990mm
Load Center :
1150mm
Foks leg (length*width) Height :
150X55mm
Grab Min. Height :
525mm
Grab Max. Height :
750mm
Net Weight :
98Kg
Warranty :
1 year
After Service :
On-line service,Spare parts
Description

Feature:

- Grab, lift, move and place drums without the operator leaving driver's seat;

- Completely Mechanical and Automatic drum grab requires no hydraulic or

electrical connections;

- Automatic clamping mechanism for handling steel and plastic drums in high

volume applications;

- Carriage mounted models are available to mount directly on the carriage of

most lift trucks for tight aisle applications;

- Can handle 1,2,3 drums simultaneously;

- Totally enclosed fork pockets with attached safety chain and cam lock secures

the attachment to the lift truck.

Specification:

Model 　 DG1080A
Capacity kg 360*3
Net Weight kg 98
Overall Size mm 1080*1520*850
Load Center mm 1150
Grab Min. Height mm 525
Grab Max. Height mm 750
Grab Middle Height mm 675--600
Foks leg (length*width) mm 150*55
Straddle inner Width mm 670
Staddle outline Width mm 990
Straddle Length mm 900
