Tile Adhesive Mixing Machine , Floor Grout Formulated Dry Mortar Equipment
Tile Adhesive Mixing Machine , Floor Grout Formulated Dry Mortar Equipment
Tile Adhesive Mixing Machine , Floor Grout Formulated Dry Mortar Equipment
Tile Adhesive Mixing Machine , Floor Grout Formulated Dry Mortar Equipment
Tile Adhesive Mixing Machine , Floor Grout Formulated Dry Mortar Equipment
Tile Adhesive Mixing Machine , Floor Grout Formulated Dry Mortar Equipment
Specifications
Brand Name :
BH
Model Number :
BH 2-5 T/H
Certification :
CE ISO SGS
Place of Origin :
China
MOQ :
1 set
Payment Terms :
L/C, T/T, D/A, D/P, Western Union, MoneyGram
Supply Ability :
85 sets per month
Delivery Time :
2-5 work days
Packaging Details :
1X20GP container for 1 set 1-5 t/h dry mortar plant.
Product name :
Tile Adhesive Machine
Mixer :
twin shaft paddle mixer
mixing tiem :
2-3 minutes
Height :
4m
Capacity :
2-5 t/h
Function :
full automatic
Warranty :
1 year
Voltage :
220V/380V/415V
Total power :
5-15kw
After-sales service provided :
Service Provided: Engineers Available To Service Machinery Overseas
mixer volume :
3300*1050*2100(mm)
Description

Floor grout formulated dry mix mortar plant tile adhesive machine

Description:

BH simple dry mortar plant can be fitted with two types of mixers, horizontal ribbon mixer and twin shaft paddle mixer according to customer's requested capacity and actual workshop height condition.

Parameter of 2-5t/h simple dry mortar plant:

model simple dry mortar plant
capacity 2-5t/h
occupied area 20m2
hight 4m
total power 5-15kw
batch and packaging annual batching and automatic packaging
mixer type twin sahft paddle mixer

BH Horizontal Ribbon Mixer Working principle:
The outer and inner screw ribbon blade driven by high speed rotating shaft,mixing the material in maximum,inner screw ribbon blade forced the material to sides,outer screw ribbon blade forced sides material to inward,mix the materials back and forth.In the same time,some material driven by screw ribbon do the radial motion,to form the convective mixing,so to achieve uniform mixing effect in relatively short time.

BH Twin Shaft Paddle Mixer Working principle:

The high efficiency twin shaft mixer adopts the paddle structure,The materials can lose weight instantly at the critical parabolic rotate speed so that can achieve best mixing effect,while the violent turnover speed shortens the mixing time in large extent,Thus the mixer is widely applied in medium and large dry mortar production lines

Mixer Features:

Horizontal Ribbon Mixer 1. Occupy area<20m2,height 3.5m,required 2-3 operation.
2. The capacity at 25-30 Ton per day.
3. It can realize automation in conveying material,mixing,filling and packing.
4. With Less cost.It's the priority option for setting up a small dry mortar factory.
Twin Shaft Paddle Mixer

1. High mixing homogeneity at 99.9%

2. High efficiency at 90~120 seconds per

batch

3. No dead corner for mixing. No residual

for discharging

4. Durable lifetime and stable

performance.

Installation site:

Tile Adhesive Mixing Machine , Floor Grout Formulated Dry Mortar Equipment

Tile Adhesive Mixing Machine , Floor Grout Formulated Dry Mortar Equipment

Tile Adhesive Mixing Machine , Floor Grout Formulated Dry Mortar Equipment
