Stone Ceramic Jaw Crusher Plant Road Construction Equipment PEX-150x750 100 Tph
Stone Ceramic Jaw Crusher Plant Road Construction Equipment PEX-150x750 100 Tph
Stone Ceramic Jaw Crusher Plant Road Construction Equipment PEX-150x750 100 Tph
Stone Ceramic Jaw Crusher Plant Road Construction Equipment PEX-150x750 100 Tph
Specifications
Brand Name :
Mind
Certification :
CE,ISO 9001
Place of Origin :
Henan, China
MOQ :
One Set
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
180 Sets per Month
Delivery Time :
7-20 Working Days
Packaging Details :
Standard Package
Product Name :
Jaw Crusher
Applications :
Stone, Mine, Ore, etc.
Model :
PEX-150*750
Adjustment Range (mm) :
10-40 mm
Capacity :
1-4 tph
Max. Input Size (mm) :
125 mm
Power :
5.5 KW
Service :
Engineers available to service overseas.
Description

Stone Ceramic Jaw Crusher Plant Road Construction Equipment PEX-150x750 100 Tph

1. Introduction of Mine Crushing Equipment Rock Stone Crusher Plant:

This series stone crusher mainly consists of body,eccentric shaft,belt pulley,jaw plate,connecting rod,adjuster,block spring etc parts.

Extensively used in mine ,metallurgy ,building material ,highway ,water conservancy and chemical industry for all kinds of medium hard ore/rock medium crushing and fine crushing ,Compressive pressure within 350 Mpa.

2. Working principle of Mine Crushing Equipment Rock Stone Crusher Plant:

This series stone crusher adopt curvilinear extrude style: The motor drive triangle belt transfer the power to the belt pulley,the belt pulley drive the eccentric shaft let the moving jaw move around the eccentic shaft,thus make the whole jaw move up and down.The angle between toggle plate and moving jaw increases when moving jaw moves up,thus push the moving jaw approach the fixed jaw. at the same time the material is cut and crushed.the angle between toggle plate and moving jaw decrease when moving jaw go down,the moving jaw away from the fixed jaw under the effect of pull rod and spring . at the moment , the broken material discarged from the outout. the jaw crusher do regular movement to broke and discharge materials with the continuous movement of motor.

3. Technical Parameters of Mine Crushing Equipment Rock Stone Crusher Plant:

Model

Inlet Size

(mm)

 Feed size(mm) Adjustable Range

Capacity

(t/h)

Speed

(r/min)

Power

(kw)

Weight

(t)
PEX-150*750 150*750 120 18-48 5--16 320 15 3.5

4. Features of Mine Crushing Equipment Rock Stone Crusher Plant:


1. Big breaking ratio
2. Product size is even
3. Simple structure
4. Reliable operation
5. Maintenanceis simple and convenient ,
6. Cost is economic and other characteristic

Stone Ceramic Jaw Crusher Plant Road Construction Equipment PEX-150x750 100 Tph

Stone Ceramic Jaw Crusher Plant Road Construction Equipment PEX-150x750 100 Tph
