FL/FG Boiling Granular Machine for Granulation and Drying in Pharmaceutical Industry
FL/FG Boiling Granular Machine for Granulation and Drying in Pharmaceutical Industry
FL/FG Boiling Granular Machine for Granulation and Drying in Pharmaceutical Industry
FL/FG Boiling Granular Machine for Granulation and Drying in Pharmaceutical Industry
Specifications
Brand Name :
SULI
Model Number :
FG、FL
Certification :
ISO9001
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Packaging Details :
According to customer requirements
Payment Terms :
T/T
Material :
SUS304 OR SUS316L
Be applicable :
Pharmaceutical food industry
Make :
Non -standard
Control System :
PLC
Description

FL/FG Introduction to vertical boiling bed drying machine:

The principle of the FL and FG series vertical boiling granular dried machine is the powder particles of the material, which is a circular fluidization state in the raw material container (fluidized bed). The atomization is sprayed into a number of particles containing adhesives. Due to the continuous drying of the material on thermal air, the water in the group grains evaporates and the adhesive solidifies.

FL/FG Boiling Granular Machine for Granulation and Drying in Pharmaceutical Industry

Application field:

◎ Pharmaceutical granules and coats
Gels: crushing particles, granular particles, capsules.
Caunce: Granules, pills protective layers, color preparation, slow release, film, enteric coated.
◎ Food granules and coats
Grunting, coffee, cocoa powder, cream, powder juice, amino acids, seasonings, and puffed foods.
◎ Pesticide, pigment pigment, dye

Performance characteristics:

◎ Through the granules of powder, improve liquidity, reduce dust flying;
◎ Make granulation through powder to improve its dissolving performance;
◎ Mixed -granulation -dryness -complete in one machine (one -step method of granular grains);
◎ Use anti -static filter materials, safe equipment operation;
◎ The adhesive atomizer uses a multi -current spray gun, the fog particles are uniform, and the qualification rate of the finished product is greatly improved;
◎ The equipment has no dead ends, and the loading and unloading materials are light and fast, and rinse.

Technical specification:

Specification 3 5 15 30 45 60 90 120 150 200 300 500
capacity 12 22 45 100 155 220 300 420 530 660 1000 1500
Processing 1.5/4.5 4/6 10/20 15/45 25/65 40/80 60/120 80/160 90/200 100/300 150/450 300/300
Fan power 2.2 3 4 5.5 7.5 11 15 18.5 18.5 22 30 37
Steam consumption 12 23 42 70 99 141 169 211 251 282 366 451
Compressed air consumption 0.3 1.3 0.3 0.4 0.4 0.6 0.6 0.9 0.9 0.9 1.3 1.5
noise (Fan isolation installation)≤75
Dimensions 1.0
×0.55
×1.8		 1.2
×0.6
×2.1		 1.25
×0.9
×2.1		 1.6
×0.9
×2.3		 1.65
×1.1
×2.4		 1.85
×1.25
×3		 1.85
×1.25
×3		 2.2
×1.65
×3.1		 2.27
×1.72
×3.1		 2.34
×1.9
×3.5		 2.8
×1.9
×3.8		 3
×2.55
×4.2

Note: FG without granular parts
