The boiling dryer is a device used to dry materials:
The boiling dryer can improve fluidity and reduce dust flying through powder granulation; improve its solubility through powder granulation; complete one-step granulation by mixing, granulating and drying in one machine; the use of antistatic filter cloth makes the equipment safe to operate; the pressure relief hole is set, and once an explosion occurs, the probability of injury to the equipment operator is small; the equipment has no dead angle, and the loading and unloading of materials is light and fast, and the flushing is clean, meeting the GMP specifications.

Working principle:
The clean hot air is distributed into the bed through the valve plate, and the wet material entering from the feeder is formed into a boiling state by the hot air. Since the hot air is in extensive contact with the material, the heat and mass transfer process is enhanced, so it can be dried in a shorter time. Entering from one end of the bed, after tens of seconds to a few minutes of boiling drying, it automatically flows out from the other end of the bed. This equipment generally operates under negative pressure.

Product features:
It can implement automated production and is a continuous drying equipment. The drying speed is fast and the temperature is low, which can ensure product quality and meet the GMP requirements for pharmaceutical production.

Application range: Drying of pharmaceuticals, chemical raw materials, food, grain processing, and feed. Such as: drying and dehumidification of raw materials, tablet granules, Chinese medicine granules, health foods, beverage granules, corn germ, feed, plastic resins, citric acid and other powdery and granular materials. The applicable material particle size is generally 0.1-6mm, and the optimal particle size is 0.5-3mm.

Technical specification:

Note: 1. Method method: 1. Star -shaped feed; 2. Star -shaped feed type and force transport and use; 3. Belt conveying; 4. user self -determined.

2. Can realize automated production.

3. In addition to the above models, it can be specially designed for users. 4. Depending on the materials, the fan power is also different.
