Automatic Premix Dry Mortar Mixing Production Line Ceramic Tile Grout Binder Machine
Automatic Premix Dry Mortar Mixing Production Line Ceramic Tile Grout Binder Machine
Automatic Premix Dry Mortar Mixing Production Line Ceramic Tile Grout Binder Machine
Automatic Premix Dry Mortar Mixing Production Line Ceramic Tile Grout Binder Machine
Automatic Premix Dry Mortar Mixing Production Line Ceramic Tile Grout Binder Machine
Automatic Premix Dry Mortar Mixing Production Line Ceramic Tile Grout Binder Machine
Automatic Premix Dry Mortar Mixing Production Line Ceramic Tile Grout Binder Machine
Automatic Premix Dry Mortar Mixing Production Line Ceramic Tile Grout Binder Machine
Specifications
Brand Name :
MG
Model Number :
MGDM3.7
Certification :
CE,SGS,FERI,BV,C/O
Place of Origin :
China
MOQ :
1 Set
Price :
USD 3000-70000/SET
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10 set within 30 days
Delivery Time :
20 working days
Packaging Details :
Wooden box and bubble plastic wrapping packing
Name :
Automatic Tile Adhesive Dry Mortar Mixer Machine
Capacity :
10-15T/H
Mixer type :
Twin Shafts Agravic Mixer Type
Mixing time :
3~5min/batch
Mixing plant height :
7-9m
Silo height :
6-12m
Warranty :
1 Year
Voltage :
Customized 220V/380V/415V
Raw material :
Sand Cement Caco3, Fly ash, Additives
Packing machine :
Valve type
Description

Automatic Premix Dry Mortar Mixing Production Line Ceramic Tile Grout Binder Machine

Description of Automatic Premix Dry Mortar Mixer Machine:

MG Full Automatic Dry Mortar Plant is based on the latest design concept in Europe, this production adopts the advanced PLC computer auto-control system, which production capacity can reach 10-70 tons per hour depend on the system configuration. Normally the full automatic dry mortar plant should consists of raw material storage system, conveying and weighting system, mixing system, packing system, air compressor system, dust collecting, PLC control system, etc.

Technical parameters of Automatic Premix Dry Mortar Mixer Machine:

No.

Name

Model

1

Raw Material Storage System

Detachable Silo

2

Conveying System

I

Screw Conveyor

II

Indoor Bucket Elevator

III

Outdoor Bucket Elevator

3

Small additives &weighting system

4

Batching & Weighing System

Batching & Weighing Hopper

5

Mixing System

I

Double Shaft Paddle Mixer

II

Premix Hopper

III

End Product Hopper

6

Packing System

Automatic Robot Valve Port Packing machine

7

Control System

PLC Control Cabinet

8

Dedust Part

Pulse Dedust Filter

9

High Pressure Air Supply

Air Compressor

10

Steel Structure

2-Layer Steel Platform

11

Bag Belt Conveyor(Optional)

Roller type belt conveyor

12

Cleaning and climbing conveyor

Dust Cleaning and climbing roller conveyor

13

Production date printer

Production date printer

14

Palletizing system

Palletizing machine

15

wrapping system

wrapping machine

Working site of Automatic Premix Dry Mortar Mixer Machine:

Automatic Premix Dry Mortar Mixing Production Line Ceramic Tile Grout Binder Machine

Automatic Premix Dry Mortar Mixing Production Line Ceramic Tile Grout Binder Machine

Automatic Premix Dry Mortar Mixing Production Line Ceramic Tile Grout Binder Machine

Automatic Premix Dry Mortar Mixing Production Line Ceramic Tile Grout Binder Machine

We are professional manufacture supplier dry mortar powder mixing equipment plant and sand dryer plant in China, supporting one-stop service for your plant. Details including working site design, foundation drawing, installation and debugging, worker training, formulations, chemicals, after-sale service and technical supports.

Any questions about the dry mortar mixer machine please send us inquiry.
