Specifications
Brand Name :
TOPSPACK
Model Number :
TP-PF-A11
Certification :
CE SGS
Place of Origin :
Shanghai
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
15 sets per month
Delivery Time :
20 work days
Packaging Details :
seaworthy plywood case
Material :
Stainless steel 304
Filling range :
1-500g
Hopper volume :
25L
Weight dosing :
By auger
Filling accuracy :
≤ 100g, ≤±2%; 100 – 500g, ≤±1%
Power supply :
3P AC208-415V 50/60Hz
Description

DS304 Semi Automatic Powder Filling Machine with high filling accuracy for Protein Powder​

General Description :

This type can do dosing and filling work. Due to the special professional design, so it is suitable to the fluidic or low-fluidity materials, like coffee powder, wheat flour, condiment, solid drink, veterinary drugs, dextrose, pharmaceuticals, powder additive, talcum powder, agriculture pesticide, dyestuff, and so on.

Features :

  • Lathing auger screw to guarantee the precise filling accuracy
  • PLC control and touch screen display
  • Servo motor drives screw to guarantee stable performance
  • Quick disconnecting hopper could be washed easily without tools
  • Can be setting to semi-auto filling by pedal switch or auto filling
  • Full stainless steel 304 material
  • Save 20 sets of formula inside the machine for later use
  • Replacing the auger parts, different products ranging from fine powder to granule and different weight can be packed
  • Multi language interface

Specification :

Model TP-PF-A11
Control system PLC & touch screen
Hopper volume 25L split hopper
Filling weight 1-500g
Weight dosing By auger
Filling accuracy

≤ 100g, ≤±2%; 100 – 500g, ≤±1%
Filling speed

40-120 times per min

Power supply

3P AC208-415V 50/60Hz

Total Power

 0.93kw
Total weight 160kg

Overall Dimensions

Overall Dimensions

Configuration List :

No. Name Pro. Brand
1 PLC Taiwan DELTA
2 Touch Screen Taiwan DELTA
3 Servo motor Taiwan DELTA
4 Servo driver Taiwan DELTA
5 Switching powder supply Schneider
6 Emergency switch Schneider
7 Contactor Schneider
8 Relay omron
9 Proximity switch Korea Autonics
10 Level sensor Korea Autonics

Detailed photos:

​A: split type hopper (simple to open the hopper and change different No. auger)

Schneider Semi Automatic Powder Packing Machine , Fast Rice Powder Packing Machine

B: handwheel to adjust filling nozzle height (suitable for different height container)

Schneider Semi Automatic Powder Packing Machine , Fast Rice Powder Packing Machine

C: Level sensor in the hopper (to control feeder automaticlly feeding)

Schneider Semi Automatic Powder Packing Machine , Fast Rice Powder Packing Machine

Factory show :

Schneider Semi Automatic Powder Packing Machine , Fast Rice Powder Packing Machine

Schneider Semi Automatic Powder Packing Machine , Fast Rice Powder Packing Machine
