16X16 Network USB Dante Audio Interface 48V 16 in 16 out 16 Channel Poe
16X16 Network USB Dante Audio Interface 48V 16 in 16 out 16 Channel Poe
16X16 Network USB Dante Audio Interface 48V 16 in 16 out 16 Channel Poe
16X16 Network USB Dante Audio Interface 48V 16 in 16 out 16 Channel Poe
16X16 Network USB Dante Audio Interface 48V 16 in 16 out 16 Channel Poe
16X16 Network USB Dante Audio Interface 48V 16 in 16 out 16 Channel Poe
Specifications
Brand Name :
FHB Audio
Model Number :
DB-1616
Certification :
CE,ROHS
Place of Origin :
China
MOQ :
2 Set
Price :
USD
Payment Terms :
T/T, Western Union
Supply Ability :
10000 Set per Month
Delivery Time :
1-10Set: 5-7day ;10-100Set:10-5Days
Packaging Details :
Standard packaging;
Products Name :
16CH Dante IO
Keyword :
Dante Audio Interface,Dante IO
Analog/Dante :
16CH
Function :
Analog and Dante signal convertion
Material :
Aluminum
Color :
Black
Application :
Conference,Education,Hotel
Warranty :
2 Years
Certificate :
CE,ROHS
Phantom power :
48V
Working Power Supply :
-10℃-40℃
Working Power :
DC 12V
Size :
486mm×156mm×110mm
Description

16X16 USB Audio Interface 16 in 16 out Transmitter Audio System 48V 16 Channel Poe Dante Network Audio Interface

Product Description:

DB series products are audio interface devices based on Dante international general protocol, which can input analog audio signals, convert them into digital audio signals, and route them to any Dante audio transmission network devices through Dante protocol, achieving features such as high quality, long distance, low delay, strong anti-interference ability, and convenient networking.

In addition, it supports access to any Dante network digital audio, conversion to analog audio signal output, and access to traditional analog audio devices such as mixing consoles, power amplifiers, and processors.The device adopts high quality AD/DA signal conversion chip, provides 48V phantom power supply, and can access higher quality capacitor mic

16X16 Network USB Dante Audio Interface 48V 16 in 16 out 16 Channel Poe


Specification:

Model No. DB-0808,DB-1616
Channel

DB-0808 (8 analog inputs, 8 analog outputs) + 8 × 8 Dante

DB-1616 (16 analog input, 16 analog output)+ 16 × 16 Dante
Sensitivity 0dB ~ 51dB,3dB/level
Digitalizing bit 24bit
Sampling rate 48k
Frequency response (20~20KHz) 20HZ ~ 20K HZ ,±0.5dB
Maximum input level (balanced) 20dBu
Maximum output level (balanced) 20dBu
Floor Noise -90dBu
THD+N ＜0.002% @ 4dBu
Analog to Digital dynamic range 118dB
Digital to Analog dynamic range 123dB
Input to output dynamic range 110dB
Input impedance (balanced) 20KΩ
Output impedance (balanced) 100Ω
Input common mode rejection 80dB @60Hz
Channel isolation @1kHz 100dB
Phantom power 48V
Working Temperature -10℃-40℃
Working Power DC 12V
Power Consumption 26W
Size 486mm×156mm×110mm

Our Dante Interface products line including:

  • 2CH Dante AVIO
  • 2CH Dante Wall Plate
  • 4CH Dante Box
  • 8CH,16CH Dante Interface

16X16 Network USB Dante Audio Interface 48V 16 in 16 out 16 Channel Poe

FAQ:

Q1: Are you manufacturer or trade company?
A: We are manufacturer,which located in Shenzhen, Guangdong, China.

Q2: Do you offer OEM&ODM service?
A: Yes, We can provide OEM or ODM Solution depends on client requirements

Q3: What's the quality standard of your products?
A: Our products has approved CE, ROHS certification.

Q4: Which place will use FHB equipment?
A: Our products are widely used in International Conference, Governments, Banks, Churches, Airports, Parliaments, Education institutes, Hotel, Private corporate conference hall etc,.

Q5: What’s the delivery time?

A:Sample order: During 5days,Bulk order:10-15days

  • Quality Assurance

Check Products one by one, to make sure all products are working excellent quality..
