SD6 Borewell Drilling Hammers Easy Operation / Maintenance Stable Speed
SD6 Borewell Drilling Hammers Easy Operation / Maintenance Stable Speed
Specifications
Brand Name :
Teamwhole
Model Number :
SD6 DTH hammer
Certification :
ISO9001:2008
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T O/A WEST UNION
Supply Ability :
2000 Pcs Per Month
Delivery Time :
25-30days
Packaging Details :
Wooden Case
Material :
Alloy steel
Processing Type :
Forging
Use :
Foundation Drilling Equipment, Piling Rigs
Product Name :
SD6 DTH Hammer
Color :
Gold other color available
External Diameter :
165-219 MM
Connection :
102,114,127 MM drill rod.
Work Pressure :
1.7-2.5Mpa
Price :
Negotiation
Description

tem: SD6 DTH pneumatic hammer for dth drill rig

Specification:

1. Item name: TH6-SD6 hammer

2. Thread: API 3 1/2" REG PIN

3. Outer diameter: 142mm, (can be larged to 146mm for the wearing resistance enhanced )

4. Working pressure: 14-24bar

5. Advantages: stable performance and high drilling rate

6. Service life: long

7. Weight: 105kg

Fetures:

1. Easy operation and maintenance

2. Easy disassemly.

3. Reliable quality, long service life.

4..Good flushing effect to ensure high drilling rate.

5.Strict quality warranty and compensation rules

6. Be certisfied by ISO9001:2008

Advanced material:

with high nickel steel, in features of high strength, heat resistance, and wearable.

Warranty:
The company responses for any quality problem caused by default of material.

Markets:

China, Chile, Brazil, Peru, Venezuela, Mexico, USA, Italy, France, Russia, Greece,Canada,Korea, South Africa, Nigeria, Korea, Israel, Malaysia, Mongolia and etc

Other details:

Price: FCA (China), FOB(China), CIF, CFR

Payment term: T/T

Technical Parameters:

tem: SD6 DTH pneumatic hammer for dth drill rig

Specification:

1. Item name: TH6 SD6 hammer

2. Thread: API 3 1/2" REG PIN

3. Outer diameter: 142mm, (can be larged to 146mm for the wearing resistance enhanced )

4. Working pressure: 14-24bar

5. Advantages: stable performance and high drilling rate

6. Service life: long

7. Weight: 105kg

Fetures:

1. Easy operation and maintenance

2. Easy disassemly.

3. Reliable quality, long service life.

4. Good flushing effect to ensure high drilling rate.

5. Strict quality warranty and compensation rules

6. Be certisfied by ISO9001:2008

Advanced material:

with high nickel steel, in features of high strength, heat resistance, and wearable.

Warranty:
The company responses for any quality problem caused by default of material.

Markets:

China, Chile, Brazil, Peru, Venezuela, Mexico, USA, Italy, France, Russia, Greece,Canada,Korea, South Africa, Nigeria, Korea, Israel, Malaysia, Mongolia and etc

Other details:

Price: FCA (China), FOB(China), CIF, CFR

Payment term: T/T

Technical Parameters:

SD6 Borewell Drilling Hammers Easy Operation / Maintenance Stable Speed

ITERM DESCRIPTION
NO PART LIST
1 TOP SUB 25LL10 PRODUCT NAME SD6
2 TOP SUB RING 115*3.55 PRODUCT CODE 06SH02
3 CHECK VALVE 25LL15 BIT TYPE QL60 WITH FOOT VALVE
4 SRPING 130*30*3.2*9.5 THREAD CONNECTION API 3 1/2 REG
5 ADJUSTING PAD B1-SW06H-A3001-12 WORKING PRESSURE (BAR) 14-24
6 AIR DISTRIBUTING SEAT B1-SW06H-A3002-20 AIR CONSUMPTION 24BAR (M3/MIN) 26
7 PISTON 06SH52-L RECONMENDED ROTATION SPEED 30-50
8 INNER CYLINDER 06SH30 OUTSIDE DIA (MM) 146
9 OUTER CYLINDER 06SH40-N LENGTH WITH OUT BITS 1163.5
10 BUSH DRIVE SUB 06SK62-F WEIGHT 90
11 BIT RETAINER RING B1-SK06H-A3001-50 NORMAL AXIAL PRESUURE (KN) 10.2
12 O RING 93*3.55 REC HOLE SIZE(MM) 152-203
13 CHUCK SLEEVE 06SH82 FLAT WENCH(MM) 102

SD6 Borewell Drilling Hammers Easy Operation / Maintenance Stable Speed
