Cemented Carbide Steel SP882 Shank DTH Drill Bits Diameter 216-311mm
Cemented Carbide Steel SP882 Shank DTH Drill Bits Diameter 216-311mm
Specifications
Brand Name :
New Diamond
Model Number :
SP882
Certification :
ISO9001:2008
Place of Origin :
Hunan, China (Mainland)
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
Western Union, T/T, L/C
Supply Ability :
According to order quantity
Delivery Time :
5-8 work days
Packaging Details :
Carton packaging and wooden box packing
Diameter (mm) :
216-311mm
No head length(mm) :
260mm
Number of vents :
2
Head shape :
Flat Face Bit/Concave Face/Convex Face
Material :
Alloy Steel
Spline Key Number :
12
Description

Cemented carbide steel SP882 shank DTH Drill Bits Diameter 216-311mm

Description

1.Button bit is well known for its high wear resistance on medium-hard to hard abrasive rock formations (between 200 Mpa to 260 Mpa compressive strength).Featuring spherical tungsten carbide inserts that is known to have strong configuration against carbide fracture.

2.Recommended for eliminating hole deviation

3.Widely used drifting and tunneling

4.Bit face design is ideal for medium-hard to hard abrasive rock

Applications

Widely used in mines, quarries, earthworks and other engineering drilling blasting hole, guardrail hole,mountain reinforcement, anchorage and other engineering holes, geothermal exploration hole, Well bore and other fields.

Specifications

SP

Head shape

Diameter

(mm)

 Number of vents

NO X button diamter

weight (KG)
Toothed Gauge Toothed

SP882

Concave Face

 216 2 Round Button 10XØ18 4XØ18+10XØ16

Convex concave

 254 2 Round Button 12XØ18 8XØ18+18XØ16

Convex concave

 311 3 Round Button 15XØ18 35XØ16

We can design and manufacture according to customers requirement of the bit diameter,the NO.of air holes,carbide buttons and the face shape.

Feature Advantage

1. Price commitment: in order to ensure the high reliability of products, raw material selection are usinggrapefruit brand products; under the same competitive conditions, and not to reduce product technicalperformance on the basis of sincerity at a favorable price to customers.


2. Quality commitment: product manufacturing and testing have quality records and inspection data; the performance of the product can withstand customer inspection.


3. Customer service: in order to create new diamond brand, enhance the visibility of enterprises,establish corporate image, we serve customers with the principle of "preferential prices, good service, reliableproduct quality" principle.

The appearance of the picture is different from that of the actual product, and the actual product is the

standard.
