DN150 ASME / ANSI B16.9 316 Stainless Steel End Caps For Pipes , Custom Ss Tube Fittings
DN150 ASME / ANSI B16.9 316 Stainless Steel End Caps For Pipes , Custom Ss Tube Fittings
DN150 ASME / ANSI B16.9 316 Stainless Steel End Caps For Pipes , Custom Ss Tube Fittings
DN150 ASME / ANSI B16.9 316 Stainless Steel End Caps For Pipes , Custom Ss Tube Fittings
Specifications
Brand Name :
KAYSUNS
Model Number :
KS-WF
Certification :
PED,ISO
Place of Origin :
China
MOQ :
100Pcs
Price :
USD
Supply Ability :
400Tons per Month
Delivery Time :
30-45days
Packaging Details :
Plastic Bags / Plywood Boxes
Material :
304, 304L, 316, 316L, 316Ti, 317L, 321, 321H, 347, 347H, 310S, 310H, 904L, 254SMO
Standard :
ASME/ANSI B16.9, MSS-SP-43, MSS-SP-75, EN/DIN, JIS B2311/2312/2313, ISO 3419, ISO 5251 etc.
Process :
Cold Forming
Type :
Welded / Seamless
OD. :
1/2" to 24" (DN15 ~DN600)
WT. :
SCH5S to SCHXXS
Description

DN150 ASME/ANSI B16.9 TP304 316 Stainless Steel Butt Weld Fittings End Caps​

The stainless steel cap pipe fittings can be used in water, , the milk industry, the beverage, makes a medicine, Chemical engineering, petroleum chemical engineering. The pipe fitting is a cap has SCH5S to SCHXXS thickness.

We also provide elliptical head, oval head, butterfly shape head in materials stainless steel, duplex and super duplex steel, alloy steel etc for vessel and customized design.

The pressure vessel head is fabricated by qualified manufacturer and ASME U stamp is available upon requirement. All of these materials are available for third party inspection, such as SGS,BV,Lloyd’s,TUV etc.

While marking we choose a specific item number as well different color shade to differentiate steel grades. We mark ANSI/ASME B16.9 Butt weld End Cap as needed with the most suitable & visible marking technique.

Composition:

Elements WP304L(wt%) / CR304L / S30403 304(wt%) / CR304 / S30400 316L (wt%) / CR316L /S31603 316 (wt%) / CR316 / S31600
(C) Carbon, max 0.03 0.08 0.03 0.08
(Mn) Manganese, max 2 2 2 2
(P) Phosphorus, max 0.045 0.045 0.045 0.045
(S) Sulfur, max 0.03 0.03 0.03 0.03
(Si) Silicon, max 1 1 1 1
(Ni) Nickel 8.0 - 12.0 8.0 - 11.0 10.0 - 14.0 10.0 - 14.0
(Cr) Chromium 18.0 - 20.0 18.0 - 20.0 16.0 - 18.0 16.0 - 18.0
(Mo) Molybdenum N/A N/A 2.0 - 3.0 2.0 - 3.0
(Fe) Iron Bal. Bal. Bal. Bal.
(Cu) Copper N/A N/A N/A N/A
(N) Nitrogen N/A N/A N/A N/A

Size: 1/2" to 24" (DN15 ~DN600)
Rate: SCH5S to SCHXXS
Standard: ASME/ANSI B16.9, MSS-SP-43, MSS-SP-75, EN/DIN, JIS B2311/2312/2313, ISO 3419, ISO 5251 etc.
Material:

▶Stainless Steel: ASTM A403 WP304, WP304L, WP304/304L, WP316, WP316L, WP316/WP316L, WP317L, WP321, WP321H, WP347, WP347H, A815 S31803 (Duplex Steel), 904L, 254SMO (W1.4301, 1.4306, 1.4948, 1.4401, 1.4404, 1.4571, 1.4438, 1.4541, 1.4878, 1.4550, 1.4845, 1.4539, 1.4547 etc.).

▶Duplex&Super Duplex: ASTM A815 S31803,S32205,S32750,S32760 (w1.4462, 1.4410, 1.4501, 1.4507 etc.)

▶Special Alloy: Monel 400, Inconel 600,625,Incoloy 800,800H, 825,Alloy 20, Hastelloy B3, C22,C276, 254SMO, Titanium alloy etc.

DN150 ASME / ANSI B16.9 316 Stainless Steel End Caps For Pipes , Custom Ss Tube Fittings

We are strength in stainless steel pipe fittings, especially for buttwelding pipe fittings. We can supply a very wide range such as 90 elbow, 45 elbow, tee, stub end, reducer, cap ends etc. For more information, please contact us.
